凯斯零件查询(27) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/65-12/68) (C-30[A]) - RIGHT DUAL WHEEL ATTACHMENT USED WITH REGULAR WHEEL EQUIPMENT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
448 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
351079R1
|
[4] |
BOLT,Hex Counter Shank, 1/2" - 20 x 23/32"
|
IH
wheel Superseded by part number: 32383
|
| 2. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 str self tapping lub
|
| 3. |
670590R1
|
[1] |
|
P
HUB, wheel RH
|
| 4. |
670694R1
|
[1] |
|
P
SPINDLE, dual wheel RH
|
| . . |
551769R1
|
[4] |
WASHER
|
IH
1-13/32 x 2 x 16 ga Superseded by part number: 495-81213
|
| 5. |
662994R91
|
[1] |
WHEEL
|
IH
RIM ASSY, RH wheel disc
|
