纽荷兰零件查询(FD20) - CRAWLER DOZER (A1.19/A[001]) - ALTERNATOR DRIVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
294 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4470778. | 4470778 | [1] | BLOWER | TOR |
| 4474878. | 4474878 | [1] | SPACER | MOD |
| 4610728. | 4610728 | [1] | BLOWER | MOD Superseded by part number: 87750659 |
| 4774424. | 4774424 | [1] | PULLEY | LEC |
| 10517071. | 10517071 | [1] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | HFIWASHER Superseded by part number: 10517073 |
| 11198371. | 11198371 | [1] | BELLEVILLE WASHER,Belleville, M10.5 | MKTLOCKWASHER Superseded by part number: 11198374 |
| 12164721. | 12164721 | [1] | NUT,M10 x 1.25, Cl 10 | TTF |
| 12646801. | 12646824 | [1] | WASHER,10.2mm ID x 25mm OD x 2mm Thk | TTF |
| 15540231. | 15540231 | [1] | SCREW,Hex, M12 x 1.25 x 20mm, Cl 10.9, Full Thd | MKTBOLT, Hex, M12 x 1.25 x 20, 10.9, Full Thd |
| 15970931. | 15970931 | [1] | BOLT,Hex, M10 x 1.25 x 35mm, Cl 10.9 | LEC Superseded by part number: 15970934 |
| 76009278. | 76009278 | [1] | BELT TENSIONER | LECBELT STRETCHER Superseded by part number: 76014633 |
| 760. | 76014633 | [1] | BELT TENSIONER | LECBELT STRETCHER |
