凯斯零件查询(27) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/65-12/68) (C-33) - LIFTING JACK ATTACHMENT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
848 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87414
|
[2] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 str self tapping lub
|
| 2. |
667552R1
|
[1] |
|
P
STEM, lower jack
|
| 3. |
662328R91
|
[1] |
|
P
SCREW ASSY, jackstem
|
| . . |
Q3481
|
[1] |
WASHER
|
IH
1-1/32 x 1-1/2 x 16 ga Superseded by part number: 86624169
|
| . . |
17175R1
|
[1] |
LOCK PIN,3/16" x 1", Slotted
|
IH
PIN, 3/16" x 1", Slotted Superseded by part number: 118827
|
| . . |
103397
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
IH
Pin, Split (Cotter), 5/32" x 1 1/4" Superseded by part number: 132-341
|
| 4. |
662326R1
|
[1] |
|
P
HANDLE, jackscrew
|
| . . |
Q1504
|
[1] |
WASHER
|
IH
13/32 x 7/8 x 16 ga Superseded by part number: 495-21044
|
| . . |
103384
|
[1] |
COTTER PIN,1/8" x 3/4"
|
IH
Pin, Split (Cotter), 1/8" x 3/4" Superseded by part number: 80755
|
| 5. |
662052R1
|
[1] |
|
P
BLOCK, jackstand
|
| 6. |
662327R1
|
[1] |
ROD
|
IH
PIN, jackstand lock
|
| 7. |
T249
|
[1] |
SPRING
|
IH
jackstand pivot pin Superseded by part number: T249-1
|
