纽荷兰零件查询(FD20) - CRAWLER DOZER (A2.01[001]) - FUEL TANK GUARD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
997 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73159065 | [1] | SUPPORT | NHRIGHT |
| 2. | 11112234 | [3] | BOLT,Hex, M12 x 25mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11112231 |
| 3. | 10571971 | [3] | LOCK WASHER | BHBWASHER Superseded by part number: 412123 |
| 4. | 73159057 | [1] | PLATE | NHCOVER |
| 5. | 73159067 | [1] | GUARD | NH |
| 6. | 73159066 | [1] | SUPPORT | NHLEFT |
| 7. | 79005240 | [6] | WASHER,16.8mm ID x 36mm OD x 8mm Thk | LEC |
| 8. | 11118537 | [6] | SCREW | LECCAPSCREW, M16 x 40 Superseded by part number: 374835 |
