凯斯零件查询(27) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/65-12/68) (C-34) - BALE CHAMBER EXTENSION ATTACHMENT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
676 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
495526R1
|
[2] |
CHAIN (AG)
|
IH
CHAIN, bale chamber extension holdup
|
| . . |
668986R1
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1 1/4", Gr 5
|
IH
BOLT, 5/16-18 x 1-1/4 sq-nk crg Superseded by part number: 280827
|
| . . |
657803R1
|
[2] |
|
P
NUT, 5/16-18 wing
|
| . . |
668569R1
|
[2] |
WASHER
|
IH
11/32 x 1-1/2 x 11 ga C-Z Superseded by part number: 87020812
|
| . . |
Q397
|
[2] |
WASHER
|
IH
11/32 x 3/4 x 16 ga Superseded by part number: 95-81069
|
| . . |
111-404
|
[2] |
CARRIAGE BOLT,Short NK, 7/16"-14 x 1 1/4", G5
|
CAS
BOLT, 7/16 x 1-1/4 sq-nk crg Superseded by part number: 86508777
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
7/16-14 hex.
|
| . . |
103322
|
[2] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
W6652
|
[2] |
WASHER
|
IH
15/32 x 1 x 16 ga Superseded by part number: 495-81158
|
| 2. |
667693R1
|
[1] |
EXTENSION
|
IH
bale chamber
|
| . . |
14996R1
|
[2] |
BOLT, 7/16 x 3/4 sq-nk crg
|
|
| . . |
664646R1
|
[2] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 hex. lock Superseded by part number: 280980
|
| . . |
Q5097
|
[2] |
WASHER
|
IH
15/32 x 1-1/4 x 16 ga Superseded by part number: 106263
|
