| 1. |
495526R1
|
[2] |
CHAIN (AG)
|
IH
CHAIN, bale chamber extension hold up
|
| . . |
668986R1
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1 1/4", Gr 5
|
IH
BOLT, 5/16-18 x 1-1/4 sq-nk crg, type 2 Superseded by part number: 280827
|
| . . |
657803R1
|
[2] |
|
P
NUT, 5/16-18 wing
|
| . . |
688569R1
|
[2] |
WASHER, 11/32 x 1-1/2 x 11 ga C-Z
|
|
| . . |
Q397
|
[2] |
WASHER
|
IH
11/32 x 3/4 x 16 ga Superseded by part number: 95-81069
|
| . . |
111-404
|
[2] |
CARRIAGE BOLT,Short NK, 7/16"-14 x 1 1/4", G5
|
CAS
BOLT, 7/16 x 1-1/4 sq-nk crg Superseded by part number: 86508777
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
7/16-14 hex.
|
| . . |
103322
|
[2] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
W6652
|
[4] |
WASHER
|
IH
15/32 x 1 x 16 ga Superseded by part number: 495-81158
|
| 2. |
667689R92
|
[1] |
|
P
EXTENSION ASSY, bale chamber RH
|
| . . |
15009R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd Superseded by part number: 412-716
|
| . . |
664646R1
|
[2] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 hex. lock Superseded by part number: 280980
|
| . . |
Q5097
|
[2] |
WASHER
|
IH
15/32 x 1-1/4 x 16 ga Superseded by part number: 106263
|
| 3. |
667692R2
|
[1] |
|
P
EXTENSION, bale chamber LH
|
| . . |
14995R1
|
[1] |
BOLT
|
IH
3/8 x 3/4 sq-nk crg Superseded by part number: 19284R1
|
| . . |
17412R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 2
|
IH
3/8 x 3/4 hex-hd mach Superseded by part number: 86500692
|
| . . |
102635
|
[3] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 4. |
669645R1
|
[1] |
|
P
BRACKET, bale chamber extension LH
|
| 5. |
669646R1
|
[1] |
|
P
BRACKET, bale chamber extension RH
|
