凯斯零件查询(27) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/65-12/68) (C-35) - TRAILER HITCH ATTACHMENT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
136 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
670700R1
|
[1] |
BAR
|
IH
trailer hitch
|
| . . |
179883
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
IH
Superseded by part number: 180175
|
| . . |
102637
|
[2] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 2. |
670699R1
|
[1] |
HITCH ASSY
|
IH
HITCH, trailer telescoping
|
| . . |
664573R1
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 hex. lock Superseded by part number: 231-4218
|
| 3. |
671637R91
|
[1] |
SUPPORT
|
IH
ASSY, trailer hitch
|
| . . |
80280503
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
|
BEL
BOLT, 3/8 x 1
|
| . . |
102635
|
[4] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[4] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
16038R1
|
[1] |
WASHER
|
IH
17/32 x 1 x 11 ga Superseded by part number: 86624146
|
| 4. |
670696R91
|
[1] |
|
P
BRACKET ASSY, trailer hitch
|
