纽荷兰零件查询(FD20) - CRAWLER DOZER (A2.22[002]) - AIR CLEANER AND DUCTS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
759 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10517071. | 10517071 | [6] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | HFILOCKWASHER Superseded by part number: 10517073 |
| 11112431. | 11112431 | [2] | SCREW,Hex, M12 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 87015736 |
| 11112631. | 11112631 | [3] | BOLT,Hex, M12 x 35mm, Cl 10.9 | LECBOLT, Hex, M12 x 35, 10.9 Superseded by part number: 626-12035 |
| 11112831. | 11112831 | [1] | SCREW,Hex, M12 x 40mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11125434 |
| 11702921. | 11702921 | [6] | NUT,M12, Cl 10 | LEC Superseded by part number: 17038425 |
| 12174790. | 12174790 | [4] | HOSE CLIP | MKTCOLLAR Superseded by part number: 17764992 |
| 12646921. | 12646921 | [6] | WASHER,12.2mm ID x 28mm OD x 3mm Thk | BHB Superseded by part number: 16887624 |
| 79017267. | 79017267 | [1] | TIE-ROD | LECROD |
| 79019081. | 79019081 | [2] | TIE-ROD | LECROD |
| 79023845. | 79023845 | [1] | RIGID TUBE | LECPIPE |
| 79023913. | 79023913 | [1] | COLLAR | LEC |
| 79025613. | 79025613 | [2] | HOSE | LECSLEEVE |
| 79025614. | 79025614 | [1] | AIR PRE-CLEANER ASSY | LECPRECLEANER |
| 79025615. | 79025615 | [1] | RIGID TUBE | LECPIPE |
