| 1. |
667743R1
|
[1] |
SHEET
|
IH
TOP SHEET, right front
|
| . . |
14995R1
|
[3] |
BOLT
|
IH
cge. 3/8 x 3/4 Superseded by part number: 19284R1
|
| . . |
102635
|
[3] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[3] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 2. |
670866R1
|
[2] |
NO LONGER SERVICED
|
IH
CHANNEL, feed opening Superseded by part number: 670866R2
|
| . . |
80280503
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
|
BEL
BOLT, cge, 3/8 x 1
|
| 3. |
667745R1
|
[1] |
SHEET
|
IH
TOP SHEET, right center
|
| . . |
137352
|
[3] |
|
P
SCREW, tr. hd. sl. 1/4 x 5/8
|
| . . |
109084
|
[3] |
NUT,1/4"-20, G5
|
IH
Superseded by part number: 7770
|
| . . |
103319
|
[3] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| 4. |
667746R1
|
[1] |
SHEET
|
IH
TOP SHEET, right rear
|
| 5. |
665437R1
|
[1] |
|
P
HOLDER, auger stop lower
|
| . . |
14986R1
|
[2] |
BOLT, cge. 5/16 x 1/2
|
|
| . . |
15053R1
|
[2] |
BOLT,Short NK, 5/16"-18 x 1 3/4", G2
|
IH
cge. 5/16 x 1-3/4 Superseded by part number: 27480R1
|
| . . |
9635082
|
[4] |
NUT,5/16" - 18, Gr 5
|
NH
5/16
|
| . . |
103320
|
[4] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 6. |
662135R1
|
[3] |
STOP
|
IH
auger
|
| 7. |
662239R1
|
[1] |
BRACKET
|
IH
HOLDER, auger stop upper
|
| . . |
15022R1
|
[2] |
BOLT,Sht Sq Nk, 5/16" - 18 x 1 1/4"
|
IH
cge. 5/16 x 1-1/4 Superseded by part number: 280827
|
| 8. |
662408R2
|
[1] |
|
P
SHEET, cross conveyor side
|
| . . |
17446R1
|
[1] |
BOLT,3/8" - 16 x 1 1/4", Gr 2
|
IH
mach, 3/8 x 1-1/4 Superseded by part number: 88011
|
| 9. |
667742R1
|
[1] |
STRAP
|
IH
feed opening tie
|
| 11. |
667731R1
|
[1] |
|
P
COVER, cross conveyor
|
| . . |
95-11028
|
[4] |
WASHER,1/4"
|
CAS
9/32 x 5/8 x .065
|
| 11. |
662151R1
|
[1] |
BRACE
|
IH
cross, conveyor platform
|
| 12. |
662357R1
|
[1] |
PLATFORM
|
IH
cross conveyor
|
| . . |
14994R1
|
[5] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2 Superseded by part number: 434-512
|
| . . |
NLS
|
[5] |
NO LONGER SERVICED
|
BAS
SCREW, fl. hd. sl. 1/4 x 3/4
|
| 13. |
655108R2
|
[1] |
GUIDE
|
IH
twine, 2 for 37T and 47T Balers
|
| . . |
106883
|
[4] |
RIVET,Truss Hd, 3/16" x 3/8"
|
IH
Superseded by part number: 87467
|
| 14. |
662383R31
|
[1] |
|
P
TOP, twine can, for twine Balers
|
| . . |
179793
|
[2] |
BOLT,Hex, 1/4" - 20 x 5/8", Gr 5, Full Thd
|
IH
Superseded by part number: 280641
|
| . . |
Q392
|
[2] |
WASHER
|
CAS
9/32 x 3/4 x 18 ga Superseded by part number: 495-21031
|
| 15. |
664813R1
|
[1] |
|
P
SHEET, cross conveyor back, for wire Balers
|
| 16. |
667738R1
|
[1] |
|
P
SHEET, rear filler, for 37T and 47T Balers
|
| 16. |
667739R1
|
[1] |
|
P
FILLER SHEET, rear, for wire Balers
|
| . . |
557109R1
|
[3] |
WASHER
|
IH
17/64 x 1/2 x 16 ga
|
| 17. |
662399R93
|
[1] |
|
P
SHEET, feed opening cpt.
|
| . . |
15551R1
|
[2] |
BOLT,3/8"-16 x 1", G2, Full Thd
|
IH
plow 3/8 x 1 Superseded by part number: 419-3616
|
| . . |
15581R1
|
[1] |
BOLT,3/8"-16 x 1 1/2", G2
|
IH
3/8-16 x 1-1/2 plow Superseded by part number: 19021R1, 118-141
|
| . . |
84896
|
[3] |
SCREW,Slotted Truss Hd, 5/16" - 18 x 3/4"
|
NH
tr. hd. sl. 5/16 x 3/4
|
| 18. |
662236R91
|
[1] |
|
P
CHANNEL, cross conveyor support, cpt.
|
| . . |
17426R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
mach. 3/8 x 1 Superseded by part number: 24840R1
|
| . . |
15563R1
|
[2] |
BOLT,3/8"-16 x 1 1/4", G2, Full Thd
|
IH
PLOW, (#3) 3/8"-16 x 1 1/4", G2, Full Thd Superseded by part number: 19031R1
|
| 19. |
667740R1
|
[1] |
|
P
KNIFE GUIDE, feed opening top sheet
|
| . . |
Q1597
|
[2] |
WASHER
|
IH
13/32 x 3/4 x 16 ga. Superseded by part number: 86632580
|
| 20. |
662248R2
|
[1] |
|
P
OPENING, front feed
|
| . . |
120572
|
[1] |
|
P
SCREW, tr. hd. sl. 1/4 x 3/4
|
| . . |
127507H
|
[1] |
WASHER
|
IH
13/32 x 7/8 x 7 ga. Superseded by part number: 21309R1
|
| 21. |
672150R1
|
[1] |
DEFLECTOR
|
IH
feed opening
|
| . . |
86508749
|
[2] |
CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 1 1/4", Grade 5
|
GI
BOLT, 3/8 x 1-1/4 sq-nk crg
|
