| 1. |
662176R91
|
[1] |
AUGER
|
IH
cpt. Superseded by part number: 754622R91
|
| . . |
Q3648
|
[1] |
PIPE
|
P
29/32 x 2 x 16 ga. Superseded by part number: NLS
|
| 2. |
495290R1
|
[4] |
BUSHING
|
IH
auger core & drive shaft
|
| . . |
Q3836
|
[1] |
WASHER
|
IH
1-11/32 x 2 x 11 ga. Superseded by part number: 495-81211
|
| 3. |
87414
|
[2] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, lub. 1/4-28 self tapping
|
| 4. |
662172R92
|
[1] |
|
P
SUPPORT & RELIEF, auger cpt.
|
| 5. |
662387R1
|
[1] |
ANCHOR
|
IH
auger relief spring
|
| . . |
Q2780
|
[4] |
WASHER
|
IH
pl. 29/32 x 1-11/32 x 20 ga. (or as required)
|
| 6. |
450398R2
|
[1] |
VALVE SPRING
|
IH
SPRING, auger relief
|
| 7. |
495170R2
|
[2] |
HUB CAP
|
IH
HUB SHEAVE V
|
| . . |
616253R1
|
[2] |
LOCK PIN,5/16" x 1 5/8", Slotted
|
IH
Pin, 5/16" x 1 5/8", Slotted Superseded by part number: 70921559
|
| 8. |
495480R1
|
[4] |
PULLEY
|
IH
SHEAVE, auger drive
|
| . . |
17470R1
|
[8] |
BOLT
|
IH
mach. 5/16 x 1-1/2 Superseded by part number: 179822
|
| . . |
9635082
|
[8] |
NUT,5/16" - 18, Gr 5
|
NH
5/16
|
| . . |
103320
|
[8] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
Q397
|
[32] |
WASHER
|
IH
11/32 x 3/4 x 16 ga Superseded by part number: 95-81069
|
| 9. |
662213R1
|
[1] |
V-BELT,0.88" W
|
IH
Auger drive 0.88" W Superseded by part number: 86517914
|
| 10. |
662258R21
|
[1] |
|
P
SHIELD W/PRODUCT GRAPHIC, auger belt
|
| . . |
19419R1
|
[4] |
BOLT, mach. cad. pl. 5/16 x 1/2
|
|
| 11. |
495473R1
|
[1] |
BRACKET
|
IH
BEARING, auger relief R.
|
| . . |
14995R1
|
[2] |
BOLT
|
IH
cge. 3/8 x 3/4 Superseded by part number: 19284R1
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 12. |
667774R1
|
[1] |
COLLAR
|
IH
auger relief pipe set
|
| . . |
102872
|
[1] |
SET SCREW
|
IH
sq. hd set cup point 1/4 x 3/4 Superseded by part number: 280194
|
| . . |
109084
|
[1] |
NUT,1/4"-20, G5
|
IH
Superseded by part number: 7770
|
| 13. |
667775R1
|
[1] |
|
P
SHAFT, auger drive
|
| 14. |
667776R1
|
[1] |
|
P
PINION, auger drive
|
| . . |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
Pin, Grooved, 5/16" x 1 3/4", Type A
|
| . . |
VC649
|
[1] |
WASHER
|
IH
29/32 x 1-3/4 x 16 ga (or as required)
|
