| 1. |
667829R91
|
[1] |
|
P
CHANNEL, upper tension cpt.
|
| 2. |
662385R11
|
[2] |
|
P
SCREW, tension adjusting, for 47 Baler
|
| . . |
12258R1
|
[2] |
WASHER
|
IH
21/32 x 1-1/4 x 11 ga. Superseded by part number: 25711R1
|
| 2. |
667994R11
|
[2] |
|
P
SCREW, tension adjusting, for 37 Baler
|
| 3. |
656934R1
|
[2] |
BUSHING
|
IH
PILOT, tension adj. screw
|
| 4. |
662028R1
|
[2] |
PLUG
|
IH
tension spring, for 47 Baler
|
| 5. |
667686R91
|
[1] |
|
P
CHANNEL, lower tension, for 47 Baler
|
| 6. |
26489B
|
[2] |
|
P
EYEBOLT, spring anchor, for 47 Baler
|
| . . |
102637
|
[2] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
16038R1
|
[2] |
WASHER
|
IH
17/32 x 1 x 11 ga. Superseded by part number: 86624146
|
| 7. |
662384R1
|
[2] |
SPRING
|
IH
bale chamber tension, for 47 Baler
|
| 8. |
667993R1
|
[2] |
|
P
SUPPORT, upper tension channel spring, for 37 Baler
|
| . . |
80280503
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
|
BEL
BOLT, 3/8-16 x 1 short-sq-nk-crg
|
| . . |
102635
|
[4] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[4] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 9. |
667837R1
|
[4] |
|
P
COLLAR, manual tension spring, for 37 Baler
|
| 10. |
667838R1
|
[2] |
SPRING
|
IH
manual tension, for 37 Baler
|
| 11. |
667995R11
|
[2] |
|
P
PLATE, bale chamber tension adjusting, for 37 Baler
|
| 12. |
667981R91
|
[1] |
|
P
CHANNEL, lower tension, for 37 Baler
|
| . . |
17426R1
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8-16 x 1 hex-hd mach. Superseded by part number: 24840R1
|
| 13. |
668764R1
|
[2] |
|
P
STRAP, tension spring
|
| . . |
18508R1
|
[2] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8-16 x 3/4 cd pltd short sq nk crg Superseded by part number: 86508748
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
