| 1. |
668129R91
|
[1] |
|
P
SHAFT, pump drive cpt
|
| . . |
142987
|
[1] |
PIN,5/16" x 2 1/2", Type A
|
IH
Grooved, 5/16" x 2 1/2", Type A Superseded by part number: 138-2029
|
| 2. |
668565R1
|
[1] |
|
P
SHIELD, pump driver shaft
|
| 3. |
668750R91
|
[1] |
BEARING ASSY
|
IH
adapter drive shaft
|
| 4. |
668134R1
|
[1] |
SPROCKET ASSY.
|
IH
SPROCKET, hydraulic pump drive
|
| . . |
19355R1
|
[1] |
LOCK PIN,3/16" x 2", Slotted
|
IH
PIN, 3/16" x 2", Slotted Superseded by part number: 438-11232
|
| 6. |
668133R1
|
[1] |
SPROCKET ASSY.
|
IH
SPROCKET, hydraulic pump driven
|
| . . |
222892
|
[1] |
SCREW,Hex Soc, #10-24 x 1/2"
|
IH
#10-24 x 1/2 hex-soc hd set Superseded by part number: 483-6108
|
| 7. |
668128R1
|
[1] |
|
P
BRACKET, hydraulic pump support
|
| . . |
19417R1
|
[2] |
BOLT
|
IH
3/8-16 x 1 cd-pltd sq-hd crg Superseded by part number: 80280503
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
469668R1
|
[2] |
WASHER
|
IH
13/32 x 3/4 x 16 ga. cd-pltd Superseded by part number: 86632580
|
| 8. |
668119R91
|
[1] |
|
P
CHANNEL, lower tension cpt.
|
| . . |
15543R1
|
[1] |
BOLT
|
IH
3/8-16 x 3/4 No. 3 plow
|
| . . |
102635
|
[1] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| 9. |
668116R91
|
[1] |
|
P
CHANNEL, upper tension cpt.
|
| 10. |
217-42
|
[1] |
REDUCER,3/8" - 18 NPT x 1/4" - 18 NPT
|
CAS
BUSHING, 3/8 x 1/4 zn-pltd reducing
|
| 11. |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
ELBOW, 1/4-90 deg. zn-pltd street
|
| 12. |
651643R92
|
[1] |
HOSE
|
IH
hydraulic 1/4 x 36
|
| 13. |
144083
|
[1] |
CLIP
|
PA
TEE, 1/4 zn-pltd pipe
|
| 14. |
201603C1
|
[1] |
GAUGE
|
IH
GAGE, hydraulic Superseded by part number: 204838C1
|
| 16. |
668124R1
|
[1] |
FRAME
|
IH
hydraulic tension jack
|
| 17. |
668123R1
|
[1] |
CHANNEL
|
IH
hydraulic tension jack
|
| 18. |
668784R1
|
[1] |
SHIELD
|
IH
hyd tension drive chain
|
| . . |
14994R1
|
[3] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2 Superseded by part number: 434-512
|
| . . |
9635082
|
[3] |
NUT,5/16" - 18, Gr 5
|
NH
5/16 hex.
|
| . . |
103320
|
[3] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 19. |
668126R1
|
[2] |
|
P
BRACKET, tie bolt guide
|
| 20. |
668125R1
|
[2] |
BOLT
|
IH
hyd tension channel tie
|
| . . |
102639
|
[4] |
NUT,5/8"-11, G5
|
IH
Superseded by part number: 280374
|
| . . |
103325
|
[2] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| . . |
615135R1
|
[6] |
WASHER
|
IH
21/32 x 1-3/4 x 11 ga.
|
| 21. |
668751R11
|
[1] |
COLLAR
|
IH
COLLAR W/SET SCREW, bearing locking
|
| . . |
19280R1
|
[3] |
SCREW,Sq Nk, 1/4" - 20 x 3/4"
|
IH
BOLT, 1/4-20 x 3/4 cd-pltd sq-nk crg
|
| . . |
120375
|
[3] |
NUT,Hex, 1/4" - 20, Gr 5
|
IH
Superseded by part number: 7770
|
| . . |
103319
|
[3] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| 22. |
192054
|
[1] |
|
P
NIPPLE, 1/4 x 2-1/2 cd-pltd nipple
|
| 23. |
963095R2
|
[1] |
|
P
SNUBBER, 1/4 NPT pressure
|
