668127R91
|
[1] |
|
P
PUMP ASSY, hydraulic
|
| . . |
9635884
|
[4] |
BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5
|
NH
5/16-18 x 1 cd-pltd hex-hd
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
103320
|
[4] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 1. |
668390R1
|
[1] |
|
P
KEY, 1/8 x 3/4 sq parallel
|
| 2. |
668387R91
|
[1] |
SEAL
|
IH
shaft oil Superseded by part number: 202996C91
|
| 3. |
668382R91
|
[1] |
LARGE PLATE
|
IH
PLATE ASSY, front Superseded by part number: H646265
|
| . . |
413-436
|
[4] |
BOLT,Hex, 1/4" - 20 x 2-1/4", Gr 5
|
CAS
SCREW, 1/4-20 hex-hd cap Superseded by part number: 87405
|
| 4. |
16006R1
|
[2] |
BALL
|
IH
3/16 cr-stl Superseded by part number: 17006R1
|
| 5. |
668391R1
|
[2] |
SPRING
|
IH
check Superseded by part number: H138420
|
| 6. |
668386R1
|
[1] |
SEAL
|
IH
diaphragm Superseded by part number: H138388
|
| 7. |
668383R1
|
[1] |
GASKET
|
IH
protector Superseded by part number: H138396
|
| 7. |
668384R1
|
[1] |
GASKET
|
IH
backup Superseded by part number: H138404
|
| 8. |
668385R1
|
[1] |
DIAPHRAGM
|
IH
Superseded by part number: 204287C1
|
| 9. |
668388R91
|
[1] |
GEAR
|
CAS
ASSY, drive
|
| 10. |
668389R91
|
[1] |
GEAR
|
IH
ASSY, idler
|
| 11. |
587594R1
|
[1] |
O-RING
|
IH
1-1/2 x 1-11/16 x 3/32 Superseded by part number: 375269R1
|
| 12. |
668399R1
|
[1] |
GASKET
|
CAS
reservoir
|
| 13. |
668398R91
|
[1] |
FILTER
|
IH
ASSY
|
| 14. |
668392R91
|
[1] |
|
P
RESERVOIR ASSY, oil
|
| . . |
129-409
|
[1] |
WING NUT,1/4"-20
|
CAS
NUT, WING, 1/4"-20 Superseded by part number: 86627130
|
| . . |
179814
|
[3] |
SPACER
|
NNA
Superseded by part number: 13-510, 13-510, 80179814
|
| 15. |
668401R1
|
[1] |
SPRING
|
IH
filter pocket
|
| 16. |
668395R11
|
[1] |
FILTER
|
CAS
POCKET W/GASKET, filter
|
| 17. |
668396R1
|
[1] |
CAP
|
CAS
filter
|
| 18. |
668394R1
|
[1] |
CAP
|
CAS
breather
|
| 19. |
668400R1
|
[1] |
FILTER
|
CAS
air
|
| 20. |
668393R11
|
[1] |
COVER
|
CAS
LID W/GASKET, reservoir
|
| 21. |
668402R1
|
[1] |
|
P
GASKET, filter pocket
|
| 22. |
668397R1
|
[1] |
GASKET
|
IH
lid
|
| 24. |
668377R91
|
[1] |
VALVE
|
IH
POPPET ASSEMBLY Superseded by part number: H83931
|
| 25. |
668378R1
|
[1] |
|
P
SPRING, variable rate
|
| 26. |
252707R1
|
[1] |
O-RING,0.103" Thk x 0.75" ID, -116, Cl 5, 75 Duro
|
IH
3/4 x 15/16 x 3/32 Superseded by part number: 86977728
|
| 27. |
114492
|
[1] |
JAM NUT,Jam, 1/4"-28, G5
|
IH
1/4 jam Superseded by part number: 86976064
|
| 28. |
668380R1
|
[1] |
RING
|
IH
O-RING, 9/16 x 11/16 x 1/16 Superseded by part number: 371544R1
|
| 30. |
668381R1
|
[1] |
|
P
SCREW, special set
|
| 31. |
668379R91
|
[1] |
|
P
KIT, adj knob repair
|
| 32. |
668403R1
|
[2] |
WASHER
|
IH
WASHER, 17/64 x 31/64 x .050 AL Superseded by part number: 64759
|
| 33. |
143162
|
[1] |
PLUG
|
IH
3/8 sq-soc-hd pipe Superseded by part number: 444783
|
| 34. |
668376R91
|
[1] |
|
P
KIT, housing repair
|
| . . |
443767
|
[2] |
AXLE PIN
|
IH
PIN, 1/4 x 1/2 dowel
|
