凯斯零件查询(37) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/63-12/88) (B-47) - POWER TAKE-OFF DRIVE SHAFT CLUTCH, WHEN ORDERED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
606 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
662270R1
|
[1] |
PLATE
|
IH
clutch pressure
|
| 2. |
662043R91
|
[1] |
DISC
|
IH
clutch cpt. Superseded by part number: 662043R92
|
| 3. |
662045R11
|
[1] |
FACING, CLUTCH
|
IH
FACING W/RIVETS
|
| . . |
113342
|
[12] |
RIVET,Tr Hd, 3/16" x 3/8", Brass
|
IH
Superseded by part number: 113356
|
| 4. |
662046R1
|
[1] |
|
P
DISC, clutch
|
| . . |
13837R1
|
[10] |
|
P
RIVET, csk. hd. 1/4 x 5/8
|
| 5. |
662044R1
|
[1] |
HOUSING, clutch lug
|
|
| 6. |
664546R11
|
[1] |
SPACER
|
IH
clutch assy., set of 7
|
| 7. |
662269R1
|
[1] |
PLATE
|
IH
clutch back
|
| . . |
17426R1
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
mach, 3/8 x 1 Superseded by part number: 24840R1
|
| . . |
103321
|
[3] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 8. |
662014R11
|
[1] |
CARRIER
|
IH
CLUTCH W/BUSHING, overrunning
|
| 10. |
662078R1
|
[1] |
BUSHING
|
IH
overrunning clutch
|
| . . |
17447R1
|
[4] |
BOLT
|
IH
mach. 7/16 x 1-1/4
|
| . . |
103322
|
[4] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 11. |
662241R1
|
[2] |
RATCHET
|
IH
DOG, overrunning clutch Superseded by part number: 3101008R1
|
| 12. |
662558R1
|
[2] |
PIN
|
IH
rod end .496 x 1-7/8
|
| 13. |
M1015
|
[7] |
SPRING
|
IH
clutch
|
| . . |
15144R1
|
[7] |
BOLT
|
IH
1/2 x sq-nk crg Superseded by part number: 598816R1
|
| . . |
664573R1
|
[7] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2 hex. lock Superseded by part number: 231-4218
|
| . . |
76730H
|
[7] |
WASHER
|
IH
17/32 x 1-1/2 x 11 ga Superseded by part number: Q3560
|
