| 1. |
568100R92
|
[1] |
YOKE
|
IH
W/LOCK PIN Superseded by part number: 568100R93
|
| 1. |
660484R21
|
[1] |
FORK
|
IH
YOKE W/LOCK PIN, for heavy duty three-knuckle drive shaft Superseded by part number: 8803645
|
| 2. |
455346R21
|
[1] |
PIN
|
IH
lock Superseded by part number: 237924A1
|
| 3. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
(Not serviced separately), order 568100R92 or 660484R21
|
| 4. |
455347R1
|
[1] |
VALVE SPRING
|
IH
SPRING, lock pin Superseded by part number: 237924A1
|
| 5. |
661406R1
|
[1] |
LOCK WASHER,4.83mm ID x 18.542mm OD x 1.65mm Thk
|
IH
X-WASHER, lock
|
| 7. |
576420R1
|
[12] |
RING
|
IH
snap
|
| 7. |
495962R1
|
[12] |
RING
|
IH
snap, for heavy duty three-knuckle drive shaft
|
| 8. |
569044R91
|
[12] |
BEARING ASSY
|
IH
needle Superseded by part number: 84355319
|
| 8. |
661671R91
|
[12] |
JOINT
|
IH
BEARING, needle, for heavy duty three-knuckle drive shaft Superseded by part number: 84355326
|
| 9. |
271284
|
[3] |
YOKE
|
NNA
1/8-27 65 deg, replaces 109460 Superseded by part number: 219-40, 219-40, NLS
|
| 11. |
569047R91
|
[3] |
REPAIR KIT
|
IH
KIT, cross repair Superseded by part number: 200464C91
|
| 11. |
660116R91
|
[3] |
NUT
|
IH
KIT, cross repair, for heavy duty three-knuckle drive shaft Superseded by part number: 84355326
|
| 12. |
666734R91
|
[1] |
YOKE
|
IH
AND SHAFT Superseded by part number: 666734R92
|
| 12. |
666741R91
|
[1] |
YOKE
|
IH
AND SHAFT, for heavy duty three-knuckle drive shaft Superseded by part number: 666741R92
|
| . . |
22970R1
|
[1] |
LOCK PIN,3/8" x 2", Slotted
|
CAS
Pin, , replaces 577247R1 3/8" x 2", Slotted Superseded by part number: 86624061
|
| 13. |
464920R1
|
[4] |
NYLON BEARING,2.08" ID x 2.8" OD x 0.38"
|
IH
nylon Superseded by part number: 47941, 579113
|
| 14. |
666735R91
|
[1] |
|
P
SHIELD
|
| 14. |
666742R91
|
[1] |
|
P
SHIELD, for heavy duty three-knuckle drive shaft
|
| 15. |
666736R1
|
[1] |
YOKE
|
IH
Superseded by part number: 666736R2
|
| 15. |
666743R1
|
[1] |
YOKE
|
IH
for heavy duty three-knuckle drive shaft
|
| 16. |
576433R2
|
[1] |
YOKE
|
CAS
splined, Replaces 573433R1
|
| 16. |
660489R1
|
[1] |
YOKE
|
IH
splined, for heavy duty three-knuckle drive shaft Superseded by part number: 29212
|
| 17. |
38904K
|
[1] |
SET SCREW,1/2" - 20 x 1-9/16"
|
IH
SCREW, set
|
| . . |
124934
|
[1] |
HOSE
|
IH
1/2-20 znd hex. jam Superseded by part number: 25-158, 25-158, NLS
|
| 18. |
666729R91
|
[1] |
|
P
SHAFT, front half
|
| 18. |
666731R91
|
[1] |
GASKET
|
CAS
SHAFT, front half, for heavy duty three-knuckle drive shaft
|
| 19. |
663101R91
|
[1] |
YOKE
|
IH
flanged Superseded by part number: 663101R92
|
| 19. |
674862R1
|
[1] |
YOKE
|
IH
flanged, for heavy duty three-knuckle drive shaft Superseded by part number: 674862R2
|
| 20. |
666737R91
|
[1] |
YOKE
|
IH
AND SHAFT
|
| 20. |
666744R91
|
[1] |
YOKE
|
IH
AND SHAFT, for heavy duty three-knuckle drive shaft Superseded by part number: 666744R92
|
| 21. |
613436R1
|
[2] |
CLAMP
|
IH
SNAP RING Superseded by part number: 56760
|
| 22. |
613437R1
|
[2] |
THRUST WASHER,62.2mm ID x 71.12mm OD x 1.7mm Thk
|
IH
thrust
|
| 23. |
666739R91
|
[1] |
|
P
SHIELD, outer
|
| 23. |
666745R91
|
[1] |
|
P
SHIELD, outer, for heavy duty three-knuckle drive shaft
|
| 24. |
666738R91
|
[1] |
|
P
SHIELD, inner
|
| 24. |
666746R91
|
[1] |
RETAINER
|
IH
SHIELD, inner, for heavy duty three-knuckle drive shaft Superseded by part number: 666746R92
|
| 25. |
613439R1
|
[1] |
BRACKET
|
IH
BEARING, inner shield Superseded by part number: 754317
|
| 26. |
86636814
|
[1] |
LUBE NIPPLE,1/4"-28 x .52" lg
|
GI
FITTING, 1/4-28 str lubrication Superseded by part number: 88775
|
| 26. |
19688R1
|
[1] |
LUBE NIPPLE,1/4"-28 x .44" lg
|
IH
FITTING, 1/4-28 str self-tap. lub, for heavy duty three-knuckle drive shaft Superseded by part number: 88775
|
| 27. |
666740R91
|
[1] |
SHAFT
|
IH
TUBE AND SLEEVE
|
| 27. |
666747R91
|
[1] |
TUBE ASSY.,2.125" OD, 24.625" Length
|
IH
TUBE AND SLEEVE, for heavy duty three-knuckle drive shaft Superseded by part number: 666747R92
|
| 28. |
666730R91
|
[1] |
|
P
SHAFT, rear half
|
| 28. |
674861R91
|
[1] |
|
P
SHAFT, rear half, for heavy duty three-knuckle drive shaft
|
| 29. |
667798R11
|
[1] |
SHIELD
|
IH
W/PRODUCT GRAPHIC, PTO brg box
|
| . . |
17411R1
|
[2] |
BOLT,Hex, 5/16"-18 X 3/4", G2
|
IH
5/16 x 3/4 hex-hd mach Superseded by part number: 179816
|
| . . |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
5/16-18 hex.
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 30. |
ST669
|
[1] |
BEARING ASSY,35mm ID
|
IH
BEARING, power take-off shaft front
|
| 32. |
667460R1
|
[1] |
BUSHING
|
IH
power take-off shaft brg
|
| . . |
186295
|
[1] |
BOLT,Hex, 1/2" - 13 x 5 1/2", Gr 5
|
IH
SCREW, 1/2-13 x 5-1/2 hex-hd cap Superseded by part number: 88576
|
| . . |
102637
|
[1] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| . . |
103323
|
[1] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 33. |
667462R1
|
[1] |
BRACKET
|
IH
power take-off shaft brg pivot
|
| 34. |
667790R91
|
[1] |
BRACKET
|
IH
PEDESTAL, power take-off
|
| . . |
662086R1
|
[1] |
|
P
SCREW, 1/2-20 x 5-1/4 dld hex-hd cap
|
| . . |
425-138
|
[1] |
SLOTTED NUT,1/2"-20, G8
|
CAS
NUT, SLOTTED, 1/2"-20, G8
|
| . . |
25-118
|
[1] |
NUT,1/2"-20, G5
|
CAS
1/2-20 hex. Superseded by part number: 425-118
|
| . . |
395-11053
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
|
CAS
17/32 x 1-1/16 x 13 ga
|
| . . |
103374
|
[1] |
COTTER PIN,3/32" x 1"
|
IH
Pin, Split (Cotter), 3/32" x 1" Superseded by part number: 280251
|
| 35. |
UA20551
|
[1] |
RING
|
IH
SNAP RING, propellar shaft bearing snap
|
| 36. |
674732R1
|
[2] |
SPACER
|
IH
WASHER
|
