卡特零件查询（730） 501-8370: PUMP GP-PISTON
广数供应链运营团队, 15 02月, 2025，浏览：
572 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 393-5152Y | [1] | VALVE GP-PUMP CONTROL(BRAKE, HYDRAULIC FAN) | |
| 2. | 474-9197 | [1] | KIT-LIMITER | |
| | | | (INCLUDES PLUG, O-RING SEAL & PISTON) |
| 3. | 335-8230 | [2] | PLUG | |
| 4. | 437-1910 | [1] | SCREW-STOP | |
| 5. | 469-3279 | [1] | SEAL-O-RING | |
| 6. | 376-0900Y | [1] | ROTATING GP-PUMP(IMPLEMENT, PILOT) | |
| 7. | 279-2491 | [1] | PLATE-PORT | |
| 8. | 379-5187 | [1] | SPRING | |
| 9. | 333-7840 | [1] | STOP | |
| 10. | 491-4966 | [1] | HOUSING | |
| 11. | 524-2894 | [1] | HEAD | |
| 12. | 524-2895 | [1] | SWASHPLATE | |
| 13. | 197-2850 | [1] | SHAFT | |
| 14. | 386-6610 | [1] | SPRING | |
| 15. | 168-2203 | [1] | SHIM-SHAFT(3-MM THK) | |
| 16. | 190-6507 | [1] | RING-STOP | |
| 17. | 3P-1210 | [1] | CONE-BEARING | |
| 18. | 8J-0412 | [1] | CUP-BEARING | |
| 19. | 9W-2109 | [1] | CONE-BEARING | |
| 20. | 9W-2110 | [1] | CUP-TAPERED ROLLER | |
| 21. | 386-6612 | [1] | BEARING-CRADLE | |
| 22. | 386-6611 | [1] | BEARING-CRADLE | |
| 23. | 6R-7943M | [1] | SCREW(M5X0.8X15-MM) | |
| 24. | 258-0139 | [1] | SEAL-SHAFT | |
| 25. | 192-7470 | [1] | SEAL-O-RING | |
| 26. | 168-3504 | [2] | SEAL | |
| 27. | 180-6213 | [4] | RING-RETAINING | |
| 28. | 095-0687M | [1] | BOLT-SOCKET HEAD(M14X2X45-MM) | |
| 29. | 9X-8979 | [1] | DOWEL | |
| 30. | 8T-8442M | [4] | BOLT-SOCKET HEAD(M6X1X30-MM) | |
| 31. | 280-7870 | [1] | GASKET | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
