| 1. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
FITTING, 1/4-28 NS 3/4 str lub Superseded by part number: 87414
|
| 2. |
659489R1
|
[1] |
|
P
CAP, pulley hub, 1963
|
| . . |
17425R1
|
[3] |
BOLT,Hex, 5/16" - 18 x 1", Gr 2
|
IH
5/16 x 1 hex-hd mach Superseded by part number: 179818
|
| . . |
103320
|
[3] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 3. |
659514R1
|
[1] |
|
P
WASHER, idler pulley thrust, 1963
|
| . . |
659517R1
|
[2] |
|
P
BOLT, 1/4 x 3/4 dld mach
|
| . . |
103319
|
[2] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| 4. |
659494R1
|
[1] |
|
P
GASKET, pulley hub cap, 1963
|
| 5. |
668110R1
|
[1] |
|
P
RETAINER, belt, unit E
|
| . . |
180121
|
[3] |
BOLT,Hex, 3/8" - 16 x 7/8", Gr 5
|
IH
SCREW, cap, 3/8 x 7/8 cd pltd Superseded by part number: 280643
|
| . . |
103321
|
[3] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
477589R1
|
[3] |
WASHER
|
IH
13/32 x 1-1/2 x 11 ga. C-Z Superseded by part number: 86637594
|
| 6. |
659490R1
|
[1] |
|
P
PULLEY, engine idler, 1963
|
| 7. |
661249R1
|
[1] |
|
P
WHEEL, crank
|
| 8. |
451894R1
|
[1] |
|
P
RACE, idler bearing, 1963
|
| 9. |
511752R91
|
[2] |
BEARING, ROLLER
|
IH
BEARING, idler pulley, 1963
|
| 10. |
659506R1
|
[1] |
SPACER
|
IH
idler pulley brg, 1963 Superseded by part number: 151478C1
|
| 11. |
662339R1
|
[1] |
BELT,3.50" W x 97.75" L
|
IH
Engine drive 3.50" W x 97.75" L
|
| 11. |
668111R1
|
[1] |
BELT,3.50" W
|
IH
Drive 3.50" W
|
| 12. |
662053R11
|
[1] |
|
P
PULLEY W/SET SCREWS, engine
|
| . . |
668506R1
|
[2] |
SCREW, 3/8-16 x 3/4 hex. soc-hd cup pt nylock set
|
|
| . . |
615237R1
|
[1] |
WASHER
|
IH
1-1/16 x 2 x 16 ga Superseded by part number: 609836R1
|
| 14. |
659493R1
|
[1] |
|
P
CUP, idler retainer, 1963
|
| 15. |
668946R91
|
[1] |
|
P
BRACKET, engine idler, cpt.
|
| . . |
615193R1
|
[1] |
WASHER
|
IH
29/32 x 1-3/8 x 16 ga. (or as req.)
|
| . . |
Q1557
|
[3] |
WASHER
|
IH
29/32 x 1-3/8 x 10 ga.
|
| . . |
103387
|
[1] |
COTTER PIN,1/8" x 1 1/2"
|
IH
Pin, Split (Cotter), 1/8" x 1 1/2" Superseded by part number: 80708
|
| 16. |
667942R1
|
[2] |
|
P
BUSHING, engine idler support
|
| . . |
180153
|
[4] |
BOLT,Hex, 7/16" - 14 x 2", Gr 5
|
IH
SCREW, cap, 7/16 x 2 cd pltd Superseded by part number: 326-732
|
| . . |
664646R1
|
[4] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, hex, Mac Lean-Fogg, 7/16 Superseded by part number: 280980
|
| . . |
103322
|
[4] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
42274H
|
[2] |
SPACER
|
IH
WASHER, 15/32 x 7/8 x 7 ga. Superseded by part number: 62036R1
|
| 17. |
663935R21
|
[1] |
|
P
SUPPORT W/BUSHINGS, engine
|
| 18. |
222-762
|
[1] |
ELBOW,90 Degree, 7/16"-20, 45 Degree Fl x 1/8" NPT
|
CAS
tube, for fuel line 90º, 7/16"-20, 45º Fl x 1/8" NPT
|
| 19. |
86534426
|
[1] |
PIPE FITTING
|
CAS
1/8 street, for fuel line Superseded by part number: CAS86534426, CAS86534426, NNA86534426
|
| 20. |
668105R1
|
[1] |
|
P
ADAPTER, engine base right
|
| . . |
17452R1
|
[2] |
BOLT,Hex, 1/2"-13 x 1 1/4", G2
|
IH
1/2-13 x 1-1/4 cd-pltd hex-hd Superseded by part number: 180175
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 21. |
668034R2
|
[1] |
|
P
ANGLE, bale chamber reinforcement
|
| . . |
18778R1
|
[4] |
SCREW,Hex, 3/8"-16 x 3/4", G2
|
IH
BOLT, 3/8 x 3/4 cd-pltd hex-hd mach Superseded by part number: 180120
|
| . . |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| 22. |
668104R1
|
[1] |
|
P
ADAPTER, engine base left
|
| . . |
413-1032
|
[1] |
BOLT,Hex, 5/8" - 11 x 2", Gr 5
|
CAS
SCREW, 5/8-11 x 2 cd-pltd hex-hd cap Superseded by part number: 86505999
|
| . . |
103325
|
[1] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 23. |
662338R1
|
[2] |
SPACER
|
IH
engine base
|
| 24. |
12989R1
|
[1] |
|
P
NIPPLE, 3/8 x 7-1/2, for oil drain Nipple, 3/8" NPT x 7 1/2"
|
| 25. |
110675
|
[1] |
CAP,3/8" NPT
|
CAS
oil drain nipple Superseded by part number: 221-1524
|
| 26. |
659495R1
|
[1] |
|
P
STOP, engine idler lever
|
| . . |
18494R1
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
mach. 3/8 x 1 cd pltd Superseded by part number: 424-616
|
| 27. |
666930R1
|
[1] |
|
P
GRIP, idler lever
|
| 28. |
27385D
|
[1] |
|
P
CLIP, loom, for 3/8 bolt on fuel line
|
| 29. |
52728D
|
[2] |
|
P
CUSHION, fuel line felt
|
| 30. |
27386D
|
[1] |
|
P
CLIP, loom, for 1/2 bolt on fuel line
|
| 31. |
667968R1
|
[1] |
|
P
SPACER, fuel tank
|
| 32. |
668410R1
|
[1] |
|
P
SUPPORT, fuel tank
|
| 33. |
668690R91
|
[1] |
|
P
TANK W/CAP, fuel
|
| 35. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
(Not serviced separately), order 668112R91
|
| 36. |
668112R91
|
[1] |
|
P
STRAP, fuel tank
|
| 37. |
667969R1
|
[1] |
|
P
SUPPORT, fuel tank
|
| 40. |
667970R91
|
[2] |
|
P
STRAP, fuel tank, cpt.
|
| . . |
19417R1
|
[2] |
BOLT
|
IH
cge. 3/8 x 1 cd pltd Superseded by part number: 80280503
|
| . . |
18784R1
|
[2] |
BOLT,Hex, 3/8"-16 x 2 3/4", G2
|
IH
mach, 3/8 x 2-3/4 cd pltd Superseded by part number: 88444
|
| . . |
120394
|
[2] |
WASHER,3/8", SAE
|
IH
WASHER, 13/32 x 13/16 x 16 cd. pl. Superseded by part number: 87016
|
| . . |
120376
|
[2] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| 41. |
668107R11
|
[1] |
|
P
ROD, hitch truss right, 1963 thru 1967
|
| . . |
280374
|
[1] |
NUT,Hex, 5/8" - 11, Gr 5
|
NH
5/8-11 cd pltd hex
|
| . . |
464623R1
|
[1] |
WASHER
|
IH
21/32 x 1-1/2 x 11 ga cd Superseded by part number: 84156177
|
| 42. |
14592D
|
[1] |
|
P
TURNBUCKLE, truss rod, 1963 thru 1967
|
| . . |
220081
|
[1] |
SEALING ELEMENT
|
NNA
3/4-10 hex Superseded by part number: 425-1012, 425-1012, 84814913
|
| 43. |
668106R11
|
[1] |
|
P
ROD, hitch truss left, 1963 thru 1967
|
| 44. |
589951R1
|
[1] |
PLUG
|
IH
CAP, hub pulley, 1964 up
|
| 45. |
651815R91
|
[1] |
BEARING ASSY,7.508" ID x 17.82" OD x 6"
|
IH
BEARING ASSY, idler pulley outer cone, 1964 up Superseded by part number: 179080
|
| 45. |
651815R91GV
|
[1] |
BEARING CONE
|
MKT
Value, Cone Bearing
|
| . . |
551177R1
|
[2] |
WASHER
|
IH
21/32 x 1-1/4 x 16 ga Superseded by part number: 131016
|
| . . |
102649
|
[1] |
SLOTTED NUT,5/8"-18, G5
|
IH
NUT, 5/8"-18, G5 Superseded by part number: 87446
|
| . . |
103385
|
[1] |
COTTER PIN,1/8" x 1"
|
IH
PIN, SPLIT (COTTER), 1/8" x 1" Superseded by part number: 80755
|
| 46. |
651814R1
|
[1] |
BEARING CUP
|
IH
BEARING, idler pulley outer cup, 1964 up Superseded by part number: 36725
|
| 47. |
564407R1
|
[1] |
|
P
PULLEY, engine idler, 1964 up
|
| 48. |
564405R1
|
[1] |
RING, SNAP
|
IH
RING, idler pulley snap, 1964 up
|
| 49. |
651817R1
|
[1] |
BEARING CUP
|
IH
BEARING, idler pulley inner cup, 1964 up Superseded by part number: 84356153
|
| 49. |
651817R1GV
|
[1] |
BEARING CUP
|
MKT
Value, Bearing Cup
|
| 50. |
651818R91
|
[1] |
ROLLER BEARING,31.77 mm ID x 16.08 mm
|
IH
BEARING ASSY, idler pulley inner cone, 1964 up Superseded by part number: 84356153
|
| 51. |
564403R91
|
[1] |
SEAL
|
IH
engine idler pulley oil, 1964 up Superseded by part number: 46876
|
| 52. |
657205R1
|
[1] |
|
P
KEY, sq. 3/8 x 3-1/4 3/8" Sq x 3 1/4", Par
|
| . . |
1001721R1
|
[1] |
|
P
DECAL, arrow, on crank wheel
|
| . . |
662982R91
|
[1] |
WISCONSIN ENGINE, manual starter
|
|
| . . |
662983R91
|
[1] |
WISCONSIN ENGINE, self contained electric unit
|
|
