纽荷兰零件查询(FD20) - CRAWLER DOZER (A2.54[001]) - INTAKE AND EXHAUST MANIFOLDS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
132 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4590346. | 4590346 | [2] | MANIFOLD GASKET | BRE Superseded by part number: |
| 4590347. | 4590347 | [4] | MANIFOLD GASKET | BRE Superseded by part number: 4854653 |
| 4616137. | 4616137 | [1] | INLET MANIFOLD | LECINTAKE MANIFOLD |
| 4616297. | 4616297 | [1] | SLEEVE | BRE Superseded by part number: 4863961 |
| 4622023. | 4622023 | [1] | GASKET | LEC Superseded by part number: 4889824 |
| 4661943. | 4661943 | [1] | BUSHING | LECBUSH |
| 4734827. | 4734827 | [1] | ELBOW | LECFLANGE |
| 4954365. | 4954365 | [1] | INLET MANIFOLD | LECINTAKE MANIFOLD |
| 10263160. | 10263160 | [1] | SEALING WASHER,M18.3 x 24 x 1 | JESGASKET |
| 10298360. | 10298360 | [1] | SEALING WASHER,M10.2 x 16 x 1, Copper | LECGASKET Superseded by part number: 4858606 |
| 11198071. | 11198071 | [3] | BELLEVILLE WASHER,Belleville, M8.4 | TORWASHER, SPRING, Belleville, M8.4 Superseded by part number: |
| 11198371. | 11198371 | [12] | BELLEVILLE WASHER,Belleville, M10.5 | MKTLOCKWASHER Superseded by part number: 11198374 |
| 11903071. | 11903071 | [1] | PLUG | MKT Superseded by part number: 16992115 |
| 12164711. | 12164711 | [12] | NUT,M10 x 1.25, Cl 8 | TTF Superseded by part number: 12164714 |
| 12174590. | 12174590 | [2] | HOSE CLIP | MKTCOLLAR Superseded by part number: 17765592 |
| 13449821. | 13449821 | [12] | STUD | MKT Superseded by part number: 13449830 |
| 13543521. | 13543521 | [3] | STUD | MKT Superseded by part number: |
| 14323911. | 14323911 | [1] | PLUG | TTF |
| 16100811. | 16100811 | [3] | NUT,Hex, M8, 6.80mm, Cl 8, ZND | TTFM8, Cl 8 Superseded by part number: 43362 |
