纽荷兰零件查询(FD20) - CRAWLER DOZER (A2.56/1[001]) - EXHAUST PIPE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
526 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10516671. | 10516671 | [2] | LOCK WASHER | BHBLOCKWASHER Superseded by part number: 83990583 |
| 10516871. | 10516871 | [11] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 11106231. | 11106231 | [4] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LECBOLT, Hex, M10 x 25, 10.9, Full Thd |
| 11106431. | 11106431 | [2] | SCREW,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LECSCREW Superseded by part number: 9515003 |
| 11701721. | 11701721 | [6] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 12164721. | 12164721 | [3] | NUT,M10 x 1.25, Cl 10 | TTF |
| 12638621. | 12638621 | [2] | WASHER,M10 x 18 x 2 | BHB Superseded by part number: 17095014 |
| 16043631. | 16043631 | [2] | SCREW,Hex, M8 x 25mm, Cl 10.9, Full Thd | BHBBOLT, Hex, M8 x 25, 10.9 Superseded by part number: 43234 |
| 16100821. | 16100821 | [2] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 70921210. | 70921210 | [2] | SCREW | MKT Superseded by part number: 70916271 |
| 76000175. | 76000175 | [2] | SCREW | MOD |
| 79007569. | 79007569 | [2] | PIN | MOD Superseded by part number: 5120754 |
| 79007570. | 79007570 | [2] | PIN | MOD Superseded by part number: 5120755 |
| 79007863. | 79007863 | [2] | BRACKET | LEC Superseded by part number: 79033288, 79033291 |
| 79007864. | 79007864 | [1] | COLLAR | LEC |
| 79011914. | 79011914 | [1] | REINFORCEMENT | LEC |
| 79025605. | 79025605 | [1] | MUFFLER | LECSILENCER |
| 79025606. | 79025606 | [1] | RIGID TUBE | LECPIPE Superseded by part number: 76019567, 76019566 |
| 79025607. | 79025607 | [1] | TIE-ROD | LECROD |
| 79025608. | 79025608 | [1] | RIGID TUBE | LECPIPE |
| 79025611. | 79025611 | [2] | GUARD | LECPROTECTION |
