纽荷兰零件查询(FD20) - CRAWLER DOZER (A2.56[001]) - EXHAUST PIPE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
976 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10516671. | 10516671 | [2] | LOCK WASHER | BHBLOCKWASHER Superseded by part number: 83990583 |
| 10516871. | 10516871 | [7] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 11106231. | 11106231 | [2] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LECBOLT, Hex, M10 x 25, 10.9, Full Thd |
| 11106431. | 11106431 | [2] | SCREW,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LECSCREW Superseded by part number: 9515003 |
| 11701721. | 11701721 | [4] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 12164721. | 12164721 | [3] | NUT,M10 x 1.25, Cl 10 | TTF |
| 12638621. | 12638621 | [2] | WASHER,M10 x 18 x 2 | BHB Superseded by part number: 17095014 |
| 12646821. | 12646821 | [2] | WASHER,10.2mm ID x 25mm OD x 2mm Thk | BHB Superseded by part number: 12646824 |
| 16043631. | 16043631 | [2] | SCREW,Hex, M8 x 25mm, Cl 10.9, Full Thd | BHBBOLT, Hex, M8 x 25, 10.9 Superseded by part number: 43234 |
| 16100821. | 16100821 | [2] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 76008011. | 76008011 | [1] | EXHAUST SYSTEM PIPE | LECSILENCER |
| 76008012. | 76008012 | [2] | GUARD | LECPROTECTION |
| 79007863. | 79007863 | [2] | BRACKET | LEC Superseded by part number: 79033288, 79033291 |
| 79011914. | 79011914 | [1] | REINFORCEMENT | LEC |
| 79011929. | 79011929 | [1] | TIE-ROD | LECROD |
| 79012951. | 79012951 | [2] | GUARD | LECPROTECTION |
| 79016679. | 79016679 | [1] | MUFFLER | LECSILENCER |
| 79016680. | 79016680 | [1] | COVER | LEC Superseded by part number: 79041120 |
| 79033288. | 79033288 | [1] | CLIP | LECHALF BRACKET |
| 79033291. | 79033291 | [1] | U-BOLT | LECHALF BRACKET |
| 79041120. | 79041120 | [1] | COVER | LEC |
