| 1. |
585856R91
|
[1] |
|
P
VALVE ASSY, top terminating, plunger stop pivot
|
| 1. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 2. |
362120R1
|
[2] |
CLAMP,9.53mm ID, 10.32mm Bolt Hole, P Type
|
IH
CLIP, for 3/8 bolt
|
| 4. |
585865R91
|
[1] |
|
P
VALVE ASSY, 180 deg top, knotter shaft
|
| 4. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4 self tap. lub
|
| 7. |
668598R91
|
[1] |
|
P
VALVE ASSY, top and tee, knotter frame pivot
|
| 7. |
580256R1
|
[1] |
ADAPTER,45 Degree, 1/8"-27
|
IH
1/8 x 45 deg elbow Superseded by part number: 217-1084
|
| 8. |
668555R1
|
[2] |
|
P
CLIP, tubing
|
| . . |
166684
|
[2] |
COVER PLATE
|
PA
SCREW, No. 10-32 x 3/8 cd-pltd cr-rec-rd-hd tap
|
| 10. |
588291R91
|
[1] |
|
P
VALVE ASSY, 90 deg top, upper Bill Hook drive shaft
|
| 10. |
586983R1
|
[1] |
|
P
ADAPTER, 1/8 x 90 deg elbow
|
| 18. |
585857R91
|
[1] |
|
P
VALVE ASSY, 90 in. terminating, lower Bill Hook drive shaft
|
| 18. |
668803R1
|
[1] |
|
P
ADAPTER, 1/4 x 90 deg elbow
|
| 19. |
631345R91
|
[1] |
|
P
VALVE ASSY, 90 deg elbow, rear packer shaft front bearing
|
| 21. |
668802R91
|
[1] |
|
P
VALVE ASSY, 90 deg top, knotter drive gear insert
|
| 26. |
585854R91
|
[1] |
|
P
VALVE ASSY, top terminating, needle pivot bearing
|
| 27. |
585594R1
|
[1] |
|
P
BODY, tee
|
| 28. |
668621R91
|
[1] |
|
P
PUMP, grease
|
| 29. |
444253
|
[1] |
TEE,1/8"-27 Fem x Male Run x Fem Br, Brass
|
IH
1/8 automotive pipe
|
| 30. |
585589R91
|
[1] |
|
P
INDICATOR, pressure
|
| 31. |
580257R1
|
[1] |
ADAPTER,60 Degree, 1/8"-27
|
IH
1/8 x 60 deg elbow
|
| 35. |
585626R1
|
[1] |
|
P
ADAPTER, 1/8 x 20 deg elbow
|
