| 1. |
668406R91
|
[1] |
|
P
PIN ASSY, hitch
|
| . . |
517843R1
|
[2] |
COTTER PIN
|
IH
PIN, 3/16 quick attachable cot. Superseded by part number: 86000109
|
| 2. |
662145R1
|
[1] |
STRAP
|
IH
hitch clevis lower
|
| . . |
NLS
|
[2] |
NO LONGER SERVICED
|
BAS
SCREW, 5/8-11 x 2-1/2 hex-hd cap
|
| . . |
9413960
|
[2] |
LOCK NUT,5/8"-11, GB
|
IH
NUT, 5/8-11 PHC hex. lock Superseded by part number: 85700693
|
| . . |
492-11062
|
[2] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 3. |
670404R1
|
[1] |
HOLDER
|
IH
STRAP, hammer hitch
|
| . . |
17452R1
|
[2] |
BOLT,Hex, 1/2"-13 x 1 1/4", G2
|
IH
1/2 x 1-1/4 C-Z hex-hd cap Superseded by part number: 180175
|
| . . |
120378
|
[2] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[2] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| 4. |
670405R1
|
[1] |
|
P
LOCK, hitch channel, 000504 thru 003106
|
| . . |
13419R1
|
[1] |
|
P
BOLT, 3/4 x 23 sq-hd mach
|
| . . |
473244R1
|
[1] |
LOCK NUT,3/4"-10, GB
|
IH
NUT, 3/4-10 znp hex. lock Superseded by part number: 231-42412
|
| 5. |
670403R1
|
[1] |
|
P
STRAP, hitch pivot
|
| . . |
271723
|
[2] |
SNAP RING,Hex, 5/8" - 11 x 2", Gr 5
|
NNA
SCREW, 5/8-11 x 2 C-Z hex-hd cap Superseded by part number: 413-1032, 413-1032, NLS
|
| . . |
425-110
|
[1] |
5/8-18 C-Z hex.
|
|
| . . |
103325
|
[2] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| . . |
413-1252
|
[1] |
BOLT,Hex, 3/4" - 10 x 3-1/4", Gr 5
|
CAS
SCREW, 3/4-10 x 3-1/4 znd hex-hd cap Superseded by part number: 88747
|
| . . |
462248R1
|
[1] |
LOCK NUT
|
IH
3/4-10 znd hex. lock Superseded by part number: 230-42112
|
| 6. |
670400R92
|
[1] |
|
P
HITCH ASSY, channel, 000504 thru 003106
|
| 6. |
674532R1
|
[1] |
HITCH ASSY
|
IH
channel, 003107 and up
|
| 7. |
662144R1
|
[1] |
STRAP
|
IH
hitch clevis upper
|
| 8. |
202673C1
|
[1] |
|
P
GUIDE, hitch, 003107 and up
|
| . . |
18496R1
|
[3] |
BOLT,Hex, 1/2"-13 x 1 1/2", G2
|
IH
1/2 x 1-1/2 znd hex-hd mach Superseded by part number: 179885
|
| 9. |
667622R2
|
[1] |
LEVER
|
IH
hitch, 003107 and up
|
| 10. |
667623R1
|
[1] |
BUSHING
|
IH
PIVOT, hitch lever, 003107 and up
|
| . . |
18815R1
|
[1] |
BOLT,Hex, 1/2"-13 x 5", G2
|
IH
1/2 x 5 znd hex-hd mach Superseded by part number: 113-429
|
| . . |
674573R1
|
[1] |
|
P
NUT, 1/2-13 hex. lock
|
| . . |
178373R1
|
[1] |
WASHER
|
IH
17/32 x 1 x 16 ga C-Z Superseded by part number: 495-51053
|
| 11. |
165
|
[1] |
SPRING
|
IH
hitch lever, 003107 and up Superseded by part number: 165-2
|
| . . |
21644R1
|
[1] |
PIN,1/4" x 1"
|
IH
Split (Cotter), 1/4" x 1" Superseded by part number: 87401
|
| . . |
18481R1
|
[1] |
COTTER PIN,3/16" x 1"
|
IH
PIN, SPLIT (COTTER), 3/16" x 1" Superseded by part number: 432-1216
|
| 12. |
667624R1
|
[1] |
NO LONGER SERVICED
|
IH
ROPE, hitch latch, 003107 and up
|
