| 1. |
673982R2
|
[1] |
|
P
CHAMBER ASSY, bale
|
| . . |
670454R1
|
[2] |
NUT
|
IH
5/16-18 speed grip
|
| 2. |
670434R1
|
[1] |
KNIFE ASSY
|
IH
KNIFE, hay
|
| . . |
21538R1
|
[1] |
CARRIAGE BOLT,#3, 5/8" - 11 x 1 1/2", Gr 2
|
IH
BOLT, 5/8-11 x 1-1/2 C-Z No. 3 repair hd plow
|
| . . |
21735R1
|
[1] |
BOLT, 5/8-11 x 1-3/4 C-Z No. 3 repair hd plow
|
|
| . . |
121358
|
[1] |
YOKE
|
NNA
5/8-18 C-Z hex. Superseded by part number: 425-1110, 425-1110, NLS
|
| . . |
492-11062
|
[2] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 3. |
200629C1
|
[1] |
DEFLECTOR
|
IH
feed opening
|
| . . |
18664R1
|
[1] |
|
P
BOLT, 3/8 x 1-1/4 C-Z sq-nk crg
|
| . . |
18422R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 2
|
IH
BOLT, 3/8 x 1-3/4 znd sq-nk crg Superseded by part number: 411-628
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
469668R1
|
[1] |
WASHER
|
IH
13/32 x 3/4 x 16 ga C-Z Superseded by part number: 86632580
|
| 4. |
673988R1
|
[1] |
|
P
REINFORCEMENT ASSY, upper bale chamber tie
|
| . . |
19019R1
|
[3] |
CARRIAGE BOLT,#3, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 C-Z No. 3 plow Superseded by part number: 419-3616
|
| . . |
17351R1
|
[3] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 C-Z sq-nk crg Superseded by part number: 88682
|
| 5. |
662294R3
|
[1] |
PLATE
|
IH
hay retainer right
|
| . . |
18508R1
|
[4] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 C-Z sq-nk crg Superseded by part number: 86508748
|
| 6. |
662147R4
|
[1] |
ANCHOR
|
IH
bale tension channel
|
| . . |
18494R1
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 2
|
IH
3/8 x 1 C-Z hex-hd mach Superseded by part number: 424-616
|
| . . |
550796R1
|
[1] |
CARRIAGE BOLT,3/8" - 16 x 1 1/4", Grade 5
|
IH
BOLT, 3/8-16 x 1-1/4 znd sq-nk crg type 5 Superseded by part number: 86508749
|
| 7. |
662215R4
|
[1] |
PLATE
|
IH
hay retainer left Superseded by part number: 671960R2
|
| 8. |
670583R1
|
[1] |
PLATE
|
IH
COVER, plunger adjusting
|
| . . |
180118
|
[9] |
BOLT,Hex, 3/8" - 16 x 5/8", Gr 5
|
IH
SCREW, 3/8-16 x 5/8 C-Z hex-hd cap Superseded by part number: 88703
|
| . . |
611346R1
|
[5] |
WASHER
|
IH
13/32 x 7/8 x 16 ga C-Z Superseded by part number: 495-81134
|
| 9. |
667685R1
|
[1] |
PIN
|
IH
hay retainer
|
| . . |
18481R1
|
[2] |
COTTER PIN,3/16" x 1"
|
IH
PIN, SPLIT (COTTER), 3/16" x 1" Superseded by part number: 432-1216
|
| 10. |
668869R1
|
[2] |
SPRING
|
IH
hay retainer
|
| 11. |
662007R2
|
[2] |
RETAINER
|
IH
hay
|
