纽荷兰零件查询(FD20) - CRAWLER DOZER (A4.03[001]) - WATER PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
729 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4606027. | 4606027 | [1] | BODY | BRE |
| 4606028. | 4606028 | [1] | COVER | BRE |
| 4606031. | 4606031 | [1] | GASKET | MKTSEAL Superseded by part number: 4757006 |
| 4606033. | 4606033 | [1] | SCREW | MKT |
| 4606034. | 4606034 | [1] | GASKET | BRE Superseded by part number: 4863953 |
| 4619257. | 4619257 | [1] | GASKET | MKTSEAL Superseded by part number: 4757008 |
| 4642042. | 4642042 | [1] | IMPELLER | BRE |
| 10257060. | 10257060 | [1] | SEALING WASHER,16.3mm ID x 22mm OD x 1.5mm Thk | BHBSEALING, M16.3 x 22 x 1.5, Copper Superseded by part number: 16508260 |
| 10268450. | 10268450 | [1] | PLUG | MKT |
| 10300771. | 10300711 | [1] | PLUG,M16 x 1.5 x 14, Cl5.8 | BAS Superseded by part number: 16992415 |
| 10725627. | 10725627 | [1] | NUT,Thin, M22 x 1.5, Cl 05, LH | LEC |
| 11198071. | 11198071 | [7] | BELLEVILLE WASHER,Belleville, M8.4 | TORWASHER, SPRING, Belleville, M8.4 Superseded by part number: |
| 13517021. | 13517021 | [3] | STUD,M8 x 12mm x 25mm, Cl 8.8 | BRE |
| 13517321. | 13517321 | [3] | STUD | BAS Superseded by part number: 13517330 |
| 13517921. | 13517921 | [1] | STUD | MKT Superseded by part number: 16730224 |
| 14044171. | 14044171 | [1] | NUT | MKT |
| 16100811. | 16100811 | [7] | NUT,Hex, M8, 6.80mm, Cl 8, ZND | TTFM8, Cl 8 Superseded by part number: 43362 |
| 79014644. | 79014644 | [1] | BEARING ASSY | LECBEARING |
| 79014646. | 79014646 | [1] | WASHER | LEC |
