纽荷兰零件查询(FD20) - CRAWLER DOZER (A4.04/1[001]) - HEAT EXCHANGER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
731 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10571779. | 10571779 | [8] | LOCK WASHER,Helical Spring, 8.10mm ID x 14.80mm OD x 2.00mm, ZNM | TTFWASHER, LOCK, M8 x 15 x 0.8 Thk Superseded by part number: 10571771 |
| 16043424. | 16043424 | [8] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 8.8, Full Thd | TTFBOLT, Hex, M8 x 20, 8.8, Full Thd |
| 79067412. | 79067412 | [1] | COVER | LEC |
| 79067413. | 79067413 | [1] | SPACER | LEC |
| 79067414. | 79067414 | [4] | GASKET | LECO-RING |
| 79067415. | 79067415 | [1] | COVER | LEC |
