纽荷兰零件查询(FD20) - CRAWLER DOZER (A4.09[001]) - FAN AND FAN DRIVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
650 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 4318965. | 4318965 | [1] | BEARING ASSY | LECBEARING Superseded by part number: 46423869 |
| 4735893. | 4735893 | [1] | PULLEY | LEC |
| 4735895. | 4735895 | [1] | PULLEY | LEC |
| 4735971. | 4735971 | [1] | PULLEY | LEC |
| 4736407. | 4736407 | [1] | COVER | LEC |
| 4745187. | 4745187 | [1] | SET OF BELTS | LECBELTS |
| 10902121. | 10902121 | [3] | SCREW,Hex, M6 x 14mm, Cl 8.8 | TTFBOLT, Hex, M6 x 14, 8.8, Full Thd Superseded by part number: 10902124 |
| 11061575. | 11061575 | [2] | LOCKING RING | MKTLOCKRING Superseded by part number: 11061576 |
| 11197771. | 11197771 | [3] | LOCK WASHER | TTFLOCKWASHER Superseded by part number: 17088474 |
| 11198371. | 11198371 | [6] | BELLEVILLE WASHER,Belleville, M10.5 | MKTLOCKWASHER Superseded by part number: 11198374 |
| 11343831. | 11343831 | [6] | SCREW,Hex, M10 x 1.25 x 50mm, Cl 10.9 | LECBOLT, Hex, M10 x 1.25 x 50, 10.9 |
| 76013063. | 76013063 | [1] | FAN | LEC Superseded by part number: 76029227 |
| 76013064. | 76013064 | [1] | FAN | LEC |
| 79021866. | 79021866 | [1] | FAN | LEC Superseded by part number: 76013063 |
| 79024484. | 79024484 | [1] | SPACER | LEC Superseded by part number: 79035740 |
| 79028862. | 79028862 | [1] | SET OF BELTS | LECBELTS Superseded by part number: 99439812 |
| 79030136. | 79030136 | [1] | FAN | LEC Superseded by part number: 76013064 |
| 79035740. | 79035740 | [1] | SPACER | LEC Superseded by part number: 98424658 |
| 79036818. | 79036818 | [1] | PULLEY | LEC |
