纽荷兰零件查询(FD20) - CRAWLER DOZER (B1.08[001]) - "CLUTCH, HOUSING AND COVERS" New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
565 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 584638. | 584638 | [1] | GASKET | MKT Superseded by part number: 76028150 |
| 5866977. | 586977 | [6] | BOLT | LEC |
| 5922075. | 592075 | [6] | WASHER,13.7mm ID x 22mm OD x 1.5mm Thk | LECGASKET |
| 10516871. | 10516871 | [12] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 11061076. | 11061076 | [2] | SNAP RING,M62, Int | ZEDRING, SNAP, M62, Int Superseded by part number: 370012 |
| 14325301. | 14325301 | [1] | PLUG | LEC Superseded by part number: 16997711 |
| 14325501. | 14325501 | [4] | PLUG | LEC Superseded by part number: 14325511 |
| 15540731. | 15540731 | [4] | SCREW,Hex, M12 x 1.25 x 45mm, Cl 10.9 | MKTBOLT, Hex, M12 x 1.25 x 45, 10.9 Superseded by part number: 15540734 |
| 15970731. | 15970731 | [4] | BOLT,Hex, M10 x 1.25 x 25mm, Cl 10.9, Full Thd | LECSCREW |
| 15970931. | 15970931 | [8] | BOLT,Hex, M10 x 1.25 x 35mm, Cl 10.9 | LEC Superseded by part number: 15970934 |
| 40002811. | 40002811 | [1] | SEAL,110mm ID x 135mm OD x 13mm Thk | MODSEAL |
| 79004435. | 79004435 | [1] | COVER | LEC Superseded by part number: 14438185, 76033280, 76027617 |
| 79018434. | 79018434 | [1] | FLANGE | LEC |
| 79020436. | 79020436 | [1] | COVER | LEC |
