| 1. |
670563R1
|
[1] |
DRIVE SPROCKET
|
IH
SPROCKET, drive knotter 39T
|
| . . |
20705R1
|
[2] |
WASHER
|
IH
1-25/32 x 2-1/2 x 16 ga C-Z Superseded by part number: 87613203
|
| . . |
21795R1
|
[2] |
WASHER,1.78" ID x 2.5" OD x 0.03" Thk
|
IH
1-25/32 x 2-1/4 x 22 ga C-Z, (or as required) Superseded by part number: 495-81005
|
| 2. |
673710R1
|
[1] |
SEPARATOR
|
IH
chain
|
| 3. |
673711R1
|
[1] |
SUPPORT
|
IH
BRACKET, chain idler
|
| . . |
18764R1
|
[1] |
HARDWARE,Hex, 5/16"-18 x 3/4", G2
|
IH
BOLT, 5/16 x 3/4 C-Z hex-hd mach Superseded by part number: 424-512
|
| . . |
120376
|
[1] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
80681
|
[1] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| . . |
18654R1
|
[1] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 2
|
IH
1/4 x 3/4 C-Z hex-hd mach Superseded by part number: 424-412
|
| . . |
120375
|
[1] |
NUT,Hex, 1/4" - 20, Gr 5
|
IH
Superseded by part number: 7770
|
| . . |
492-11025
|
[1] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| . . |
20600R1
|
[1] |
WASHER
|
IH
9/32 x 3/4 x 11 ga C-Z Superseded by part number: 86624138
|
| 5. |
673666R1
|
[2] |
CAP
|
IH
block tightener end
|
| . . |
18710R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 3", Gr 2
|
IH
BOLT, 1/2 x 3 C-Z sq-nk crg Superseded by part number: 80280818
|
| . . |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| . . |
460908R1
|
[1] |
WASHER
|
IH
17/32 x 1-1/2 x 11 ga C-Z Superseded by part number: 86624147
|
| 6. |
668147R1
|
[1] |
BLOCK
|
IH
knotter idler Superseded by part number: 667459R1
|
| 7. |
674012R1
|
[1] |
SUPPORT
|
IH
BRACKET, knotter chain tightener
|
| . . |
20897R1
|
[2] |
BOLT,Short NK, 3/8"-16 x 2 1/2", G2
|
IH
3/8 x 2-1/2 znd sq-nk crg Superseded by part number: 111-349
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 8. |
670664R1
|
[1] |
CHANNEL
|
IH
BRACKET, center knotter drive idler
|
| . . |
18508R1
|
[2] |
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 3/8 x 3/4 C-Z sq-nk crg Superseded by part number: 86508748
|
| 9. |
667459R1
|
[1] |
BLOCK
|
IH
idler
|
