| 1. |
674024R1
|
[1] |
X
|
IH
CHANNEL ASSY, lower tension
|
| . . |
17142R1
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3 1/2", Gr 2
|
IH
BOLT, 3/8 x 3-1/2 znd sq-nk crg Superseded by part number: 111-337
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| 2. |
674025R1
|
[1] |
X
|
IH
CHANNEL, upper tension
|
| 3. |
671126R91
|
[2] |
SUPPORT
|
IH
ASSY, bale tension
|
| . . |
20485R1
|
[2] |
BOLT,Short NK, 7/16"-14 x 3/4", G5. Full Thd
|
IH
7/16 x 3/4 C-Z sq-nk crg
|
| . . |
473213R1
|
[2] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 C-Z hex. lock Superseded by part number: 280980
|
| 4. |
670680R1
|
[1] |
SPRING
|
IH
tension channel
|
| . . |
18700R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 7/16" - 14 x 3", Gr 2
|
IH
BOLT, 7/16 x 3 C-Z sq-nk crg Superseded by part number: 411-748
|
| . . |
271501
|
[1] |
SOCKET
|
NNA
NUT, 7/16-14 C-Z hex.
|
| . . |
120383
|
[1] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 5. |
670681R91
|
[2] |
SCREW
|
IH
ASSY, tension adjusting
|
| . . |
589068R1
|
[2] |
WASHER
|
IH
21/32 x 1-1/4 x 11 ga C-Z Superseded by part number: 495-51066
|
| 6. |
23372S
|
[2] |
SPACER,1/2" Pipe x 2 9/16"
|
IH
1/2 x 2-9/16 std pipe
|
