纽荷兰零件查询(FD20) - CRAWLER DOZER (B1.11[002]) - OIL PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
396 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10516871. | 10516871 | [4] | LOCK WASHER,10.2mm ID x 17.7mm OD x 2.5mm Thk | HFILOCKWASHER Superseded by part number: 10571873 |
| 14466081. | 14466081 | [3] | O-RING,101.19mm ID x 3.53mm Width | LEC Superseded by part number: 70934717 |
| 15973431. | 15973431 | [4] | BOLT,Hex, M10 x 1.25 x 185, 10.9 | LECSCREW |
| 79004534. | 79004534 | [1] | SPACER | LEC Superseded by part number: 79108103, 79108103, 79111337 |
| 79004535. | 79004535 | [1] | ALTERNATOR STATOR | LECSTATOR Superseded by part number: 79004536 |
| 79004538. | 79004538 | [1] | COVER | LEC Superseded by part number: 76010238 |
| 79004543. | 79004543 | [2] | ROLLER BEARING,20 mm ID x 26 mm OD x 16 mm | LECBEARING Superseded by part number: 79014353 |
| 79004545. | 79004545 | [1] | GEAR | LECDRIVING GEAR Superseded by part number: 76020286 |
| 79004546. | 79004546 | [2] | RING | LECTHRUST RING |
| 79004592. | 79004592 | [2] | PIN | LEC |
| 79014099. | 79014099 | [2] | RING | LEC |
| 79014338. | 79014338 | [1] | ALTERNATOR STATOR | LECSTATOR |
| 79014339. | 79014339 | [1] | GEAR | LECDRIVING GEAR Superseded by part number: 76020286 |
| 79014340. | 79014340 | [1] | GEAR | LECDRIVING GEAR |
| 79014341. | 79014341 | [1] | GEAR | LECDRIVEN GEAR Superseded by part number: 76020286, 76020286, 79108103 |
| 79014342. | 79014342 | [3] | KEY | LECFEATHER KEY |
| 79014353. | 79014353 | [2] | ROLLER BEARING,20 mm ID x 26 mm OD x 16 mm | LECBEARING Superseded by part number: 822987 |
