| 2. |
455347R1
|
[1] |
VALVE SPRING
|
IH
SPRING, lock pin unit Superseded by part number: 237924A1
|
| 3. |
661406R1
|
[1] |
LOCK WASHER,4.83mm ID x 18.542mm OD x 1.65mm Thk
|
IH
X lock
|
| 4. |
455346R21
|
[1] |
PIN
|
IH
lock unit Superseded by part number: 237924A1
|
| 6. |
568100R92
|
[1] |
YOKE
|
IH
W/QA PIN Superseded by part number: 568100R93
|
| 7. |
576420R1
|
[8] |
RING
|
IH
brg retainer snap
|
| 8. |
569044R91
|
[8] |
BEARING ASSY
|
IH
ASSY, cross Superseded by part number: 84355319
|
| 10. |
80711
|
[2] |
LUBE NIPPLE,65 Degree, 1/8" NPT x 7/8" lg
|
NH
FITTING, 1/8-27, 65 deg lub
|
| 11. |
569047R91
|
[2] |
REPAIR KIT
|
IH
KIT, cross service Superseded by part number: 200464C91
|
| 12. |
667816R91
|
[1] |
YOKE
|
IH
& SHAFT ASSY, rectangular
|
| 13. |
613436R1
|
[2] |
CLAMP
|
IH
RING, snap Superseded by part number: 56760
|
| 14. |
613437R1
|
[2] |
THRUST WASHER,62.2mm ID x 71.12mm OD x 1.7mm Thk
|
IH
thrust
|
| 15. |
613439R1
|
[2] |
BRACKET
|
IH
BEARING, nylon support Superseded by part number: 754317
|
| 16. |
668405R91
|
[1] |
SHIELD
|
IH
outer
|
| 17. |
670708R1
|
[1] |
|
P
SHIELD ASSY, inner, 000504 thru 002381
|
| 17. |
668404R91
|
[1] |
SHIELD
|
IH
inner, 002382 and up
|
| 18. |
464920R1
|
[1] |
NYLON BEARING,2.08" ID x 2.8" OD x 0.38"
|
IH
nylon Superseded by part number: 47941, 579113
|
| 19. |
19688R1
|
[1] |
LUBE NIPPLE,1/4"-28 x .44" lg
|
IH
FITTING, 1/4-28 str lub Superseded by part number: 88775
|
| 20. |
667817R91
|
[1] |
YOKE
|
IH
ASSY, tube & sleeve
|
| 21. |
670707R11
|
[1] |
|
P
YOKE ASSY, flange, 000504 thru 002381
|
| 21. |
663101R91
|
[1] |
YOKE
|
IH
flanged, 002382 and up Superseded by part number: 663101R92
|
| 22. |
19629R91
|
[2] |
|
P
FITTING, 1/4-28, 67-1/2 deg self tap.
|
| 23. |
670706R91
|
[1] |
|
P
SHAFT ASSY, main drive rear half, 000504 thru 002381
|
| 23. |
668371R91
|
[1] |
JOINT
|
IH
SHAFT ASSY, implement half, 002382 and up Superseded by part number: 668371R92
|
| 24. |
668370R91
|
[1] |
JOINT
|
IH
SHAFT ASSY, main drive front half Superseded by part number: 668370R92
|
