神钢零件查询(F4HFE613S A003) - ENGINE 504386128 - YN02P00090P1 (7/13-) (10.414.01) - FAN DRIVE (504227913 - 504226781 - 504166030) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
311 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2855881 | [1] | FAN HOUSING | TORASSY Superseded by part number: 504202791 |
| 2. | 4895323 | [4] | FLANGE BOLT,Hex, M8 x 1.25 x 40mm | LEC |
| 3. | 2855972 | [1] | PULLEY,228mm OD | TOR |
| 4. | 2854320 | [1] | SPACER | TOR Superseded by part number: 504054732 |
| 5. | 2852171 | [1] | SNAP RING | TOR Superseded by part number: 32324 |
| 6. | 16592824 | [1] | BOLT,M10 x 1.5 x 70mm | TOR Superseded by part number: 16676834 |
| 7. | 4892732 | [1] | BALL BEARING,34mm ID x 64mm OD x 37mm W | TOR |
| 8. | 4892426 | [1] | HUB | TOR |
| 9. | 4890732 | [1] | RETAINER,11.50mm ID x 52mm OD x 7mm | TOR |
| 10. | 2855882 | [1] | BRACKET | TOR |
| 11. | 4899109 | [4] | SCREW,Hex, M10 x 1.5 x 80 | BAS |
