纽荷兰零件查询(FD20) - CRAWLER DOZER (D3.31[001]) - TRACK FRAME CROSS BAR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
524 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10517271. | 10517271 | [12] | LOCK WASHER,16.2mm ID x 27.7mm OD x 4mm Thk | BHBLOCKWASHER Superseded by part number: 10572173 |
| 12164127. | 12164127 | [12] | NUT,M16 x 1.5, Cl 10 | LEC Superseded by part number: 12164124 |
| 14259230. | 14259230 | [12] | SCREW,M16 x 1.5 x 100mm | LEC |
| 15835237. | 15835237 | [12] | SCREW,Hex, M16 x 1.5 x 70mm, Cl 10.9 | BHB Superseded by part number: 15835231 |
| 15981337. | 15981337 | [12] | BOLT,Hex, M16 x 1.5 x 75mm, Cl 10.9 | MODSCREW Superseded by part number: 15981334 |
| 79005992. | 79005992 | [6] | GUIDE | LEC |
| 79005993. | 79005993 | [2] | SPACER | LEC |
| 79005994. | 79005994 | [1] | SHIM | LEC |
| 79005995. | 79005995 | [1] | SHIM | LEC |
| 79005996. | 79005996 | [1] | SHIM | LEC |
