纽荷兰零件查询(FD20) - CRAWLER DOZER (D3.33[001]) - DRIVE SPROCKET New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
607 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 589062. | 589062 | [2] | BALL BEARING,152.4mm ID x 222.28mm OD x 100.72mm W | LECBEARING |
| 589063. | 589063 | [2] | THRUST PLATE | LECTHRUST RING |
| 589074. | 589074 | [2] | RING | LECRETAINER |
| 589082. | LEC589082 | [2] | RING NUT | LECTHREADED RING |
| 589261. | 589261 | [1] | HALF-RING | LECHALF RING |
| 589262. | 589262 | [1] | HALF-RING | MKTHALF RING Superseded by part number: 589261 |
| 589263. | 589263 | [1] | HALF-RING | MKTHALF RING Superseded by part number: 589261 |
| 591908. | 591908 | [2] | CIRCLIP | LECRETAINER |
| 593753. | 593753 | [4] | SEAL | MKTSEAL Superseded by part number: 76012484 |
| 4955004. | 4955004 | [2] | WHEEL | LECBEARING CASE |
| 4955005. | 4955005 | [2] | COVER | LEC |
| 10517071. | 10517071 | [24] | LOCK WASHER,12.2mm ID x 21.1mm OD x 3.1mm Thk | HFILOCKWASHER Superseded by part number: 10517073 |
| 11071375. | 11071375 | [2] | LOCKING RING | MKTLOCKRING Superseded by part number: 11071376 |
| 11082475. | 11082475 | [2] | RING | LECLOCKRING |
| 14468280. | 14468280 | [2] | GASKET | MKTSEAL Superseded by part number: 87302761 |
| 15540831. | 15540831 | [24] | BOLT,Hex, M12 x 1.25 x 50mm, Cl 10.9 | TTFBOLT, Hex, M12 x 1.25 x 50, 10.9 |
| 24904820. | 24904820 | [2] | ROLLER BEARING,120mm ID x 200mm OD x 62mm W | MKTBEARING |
| 24941330. | 24941330 | [2] | BEARING ASSY | LECBEARING Superseded by part number: 79031729 |
| 76000518. | 76000518 | [4] | BRAKE LINING | LECSEAL Superseded by part number: 593753 |
| 79003692. | 79003692 | [54] | NUT | LEC |
| 79018426. | 79018426 | [2] | HUB | LEC Superseded by part number: 79030907 |
| 79018427. | 79018427 | [54] | BOLT,M24 x 2 x 75mm, Cl 10.9 | LEC |
| 79018522. | 79018522 | [18] | TOOTHED SECTOR | LECSECTOR |
| 79018816. | 79018816 | [8] | COVER PLATE | LECLOCKPLATE |
| 79018852. | 79018852 | [2] | SHAFT | LEC Superseded by part number: 79020072 |
| 79018853. | 79018853 | [2] | RING NUT | LECTHREADED RING |
| 79018854. | 79018854 | [2] | RING NUT | LECPLUG Superseded by part number: 76009260, 76009239 |
| 79030907. | 79030907 | [2] | HUB | LEC |
| 79031729. | 79031729 | [2] | BEARING ASSY,95 mm ID x 170 mm OD x 43 mm | LECBEARING Superseded by part number: 13713214, 76009240, 76009262 |
| 79035336. | 79035336 | [18] | TOOTHED SECTOR | LECSECTOR Superseded by part number: 76028000 |
