凯斯零件查询(420) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/71-12/76) (D-40[A]) - BALE CHAMBER EXTENSION ATTACHMENT, WHEN ORDERED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
472 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
495526R1
|
[2] |
CHAIN (AG)
|
IH
CHAIN, bale chamber ext hold-up
|
| . . |
668986R1
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1 1/4", Gr 5
|
IH
BOLT, 5/16-18 x 1-1/4 znp sq-nk crg Superseded by part number: 280827
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
668569R1
|
[2] |
WASHER
|
IH
11/32 x 1-1/2 x 11 ga C-Z Superseded by part number: 87020812
|
| . . |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| . . |
619855R1
|
[2] |
WASHER
|
IH
11/32 x 3/4 x 16 ga C-Z Superseded by part number: 86637953
|
| . . |
18421R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2
|
IH
BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G5, Full Thd Superseded by part number: 412-716
|
| . . |
21331R1
|
[2] |
WASHER
|
IH
15/32 x 1-1/4 x 16 ga Superseded by part number: 106265
|
| . . |
473213R1
|
[2] |
LOCK NUT,7/16"-14, GB
|
IH
NUT, 7/16-14 C-Z hex lock Superseded by part number: 280980
|
| 2. |
667693R1
|
[1] |
EXTENSION
|
IH
bale chamber
|
| . . |
20485R1
|
[2] |
BOLT,Short NK, 7/16"-14 x 3/4", G5. Full Thd
|
IH
7/16 x 3/4 C-Z sq-nk crg
|
| 3. |
754484R1
|
[2] |
NOZZLE HOLDER
|
IH
HOLDER, chain Superseded by part number: 754484R2
|
