凯斯零件查询(420) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/71-12/76) (D-41) - TRAILER HITCH ATTACHMENT, WHEN ORDERED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
305 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
670700R1
|
[1] |
BAR
|
IH
trailer hitch
|
| . . |
180175
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
IH
SCREW, 1/2-13 x 1-1/4 C-Z hex-hd cap Superseded by part number: 113-417
|
| . . |
120378
|
[2] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[2] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| 2. |
670699R1
|
[1] |
HITCH ASSY
|
IH
HITCH TRAILER TELESCOPING
|
| . . |
474848R1
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 CDP hex. lock Superseded by part number: 231-4218
|
| . . |
607895R1
|
[1] |
WASHER
|
IH
17/32 x 1 x 11 ga C-Z Superseded by part number: 86624146
|
| 3. |
671637R91
|
[1] |
SUPPORT
|
IH
ASSY, trailer hitch
|
| . . |
17351R1
|
[4] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 C-Z sq-nk crg Superseded by part number: 88682
|
| . . |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[4] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 4. |
674041R1
|
[1] |
HITCH ASSY
|
IH
trailer stationary
|
