凯斯零件查询(420) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/71-12/76) (D-44[A]) - NEEDLE GUARD ATTACHMENT, WHEN ORDERED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
165 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
674005R1
|
[2] |
SPARE PART
|
IH
GUARD, needle Superseded by part number: 674005R2
|
| . . |
180147
|
[4] |
SCREW,Hex, 7/16" - 14 x 1 1/4", Gr 5
|
IH
7/16-14 x 1-1/4 znp hex-hd cap Superseded by part number: 9627887
|
| . . |
271501
|
[4] |
SOCKET
|
NNA
NUT, 7/16-14 znd hex.
|
| . . |
120383
|
[4] |
LOCK WASHER,Helical Spring, 7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| . . |
607891R1
|
[4] |
WASHER
|
IH
15/32 x 1 x 16 ga C-Z Superseded by part number: 495-81158
|
| . . |
17351R1
|
[4] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 znd sq-nk crg Superseded by part number: 88682
|
| . . |
120377
|
[4] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[4] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
469668R1
|
[4] |
WASHER
|
IH
13/32 x 3/4 x 16 ga C-Z Superseded by part number: 86632580
|
| 2. |
674971R1
|
[1] |
|
P
ANCHOR, plunger stop cable
|
| . . |
18778R1
|
[2] |
SCREW,Hex, 3/8"-16 x 3/4", G2
|
IH
BOLT, 3/8 x 3/4 znd hex-hd mach Superseded by part number: 180120
|
