| 1. |
669018R1
|
[1] |
BAR
|
IH
trailer hitch adjusting
|
| 2. |
662438R1
|
[1] |
PIN
|
IH
trailer hitch adjusting
|
| . . |
18481R1
|
[1] |
COTTER PIN,3/16" x 1"
|
IH
PIN, SPLIT (COTTER), 3/16" x 1" Superseded by part number: 432-1216
|
| 3. |
201354C1
|
[1] |
|
P
PIPE, trailer hitch, replaces 662437R2
|
| 4. |
674394R1
|
[1] |
TRAILER HITCH
|
IH
HITCH ASSY, trailer Superseded by part number: 674394R2
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 znd sq-nk crg Superseded by part number: 88682
|
| . . |
120377
|
[2] |
NUT,3/8" - 16, Gr 5
|
IH
Superseded by part number: 280136
|
| . . |
120382
|
[2] |
LOCK WASHER,Helical Spring, 3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 5. |
669015R2
|
[1] |
ANCHOR
|
IH
trailer hitch
|
| . . |
180177
|
[1] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5
|
IH
SCREW, 1/2-13 x 1-1/2 znd hex-hd cap Superseded by part number: 113-410
|
| . . |
474848R1
|
[2] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 znd hex. lock Superseded by part number: 231-4218
|
| . . |
120384
|
[2] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| 6. |
201355C1
|
[1] |
|
P
SUPPORT, trailer hitch
|
| . . |
180122
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
IH
3/8-16 x 1 znd hex-hd cap Superseded by part number: 113-207
|
| . . |
472144R1
|
[2] |
NUT
|
IH
3/8-16 znd hex. Superseded by part number: 385525R1
|
| . . |
180175
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
IH
SCREW, 1/2-13 x 1-1/4 znd hex-hd cap Superseded by part number: 113-417
|
| . . |
120378
|
[2] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 7. |
201356C1
|
[1] |
|
P
STRAP, axle support
|
| . . |
18684R1
|
[2] |
BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2
|
IH
3/8 x 1-1/4 znd sq-nk crg Superseded by part number: 550796R1
|
