纽荷兰零件查询(FD20) - CRAWLER DOZER (F2.01[001]) - STARTER MOTOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
692 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 70649665. | 70649665 | [1] | SPRING | MOD |
| 70910510. | 70910510 | [2] | NUT | BHB |
| 70912731. | 70912731 | [12] | SCREW | CMI |
| 70913744. | 70913744 | [4] | NUT | MKT Superseded by part number: 70910510 |
| 70916964. | 70916964 | [13] | LOCK WASHER | MODLOCKWASHER Superseded by part number: 70904204 |
| 70921400. | 70921400 | [5] | SCREW | CMI |
| 70923558. | 70923558 | [1] | INSULATING RING | MODSEAL Superseded by part number: 49886 |
| 70923560. | 70923560 | [1] | O-RING | MODSEAL Superseded by part number: 49856 |
| 70923819. | 70923819 | [2] | O-RING,0.139" Thk x 4.359" ID, -245, Cl 5, 75 Duro | MKTSEAL Superseded by part number: 86629633 |
| 70924100. | 70924100 | [5] | SCREW | MOD |
| 70927726. | 70927726 | [2] | INSULATING RING | MODRING Superseded by part number: 272464 |
| 73112215. | 73112215 | [1] | LOCK WASHER | MODWASHER Superseded by part number: 70912441 |
| 73116823. | 73116823 | [1] | SLEEVE | MODBUSHING Superseded by part number: A42308 |
| 73116830. | 73116830 | [1] | SWITCH | CMI Superseded by part number: 73127840 |
| 73116831. | 73116831 | [1] | KIT | CMI-CONSISTING OF: |
| 73116846. | 73116846 | [6] | COVER PLATE | CMIINSULATOR |
| 73116852. | 73116852 | [1] | DRIVEN SPROCKET | CMICOUPLING Superseded by part number: 73130587 |
| 73116858. | 73116858 | [12] | COMMUTATOR BRUSH | CMIBRUSH |
| 73116859. | 73116859 | [3] | INSULATOR | MOD |
| 73116869. | 73116869 | [3] | PLUG | MOD |
| 73116871. | 73116871 | [1] | GASKET | MODRING |
| 73116872. | 73116872 | [1] | LEVER | MOD |
| 73116877. | 73116877 | [1] | ARMATURE | CMI |
| 73116878. | 73116878 | [1] | FRAME | CMICOVER Superseded by part number: 73130583 |
| 73116879. | 73116879 | [1] | PLATE | CMIBRUSH HOLDER |
| 73116881. | 73116881 | [1] | COIL | CMI |
| 73116882. | 73116882 | [1] | HOUSING | CMISUPPORT Superseded by part number: 73130593 |
| 73116883. | 73116883 | [1] | BRACKET | CMI |
| 73116888. | 73116888 | [1] | SEALING WASHER | MODWASHER |
| 73116889. | 73116889 | [1] | PLUNGER | MOD |
| 73116890. | 73116890 | [1] | SEALING WASHER | MODWASHER |
| 73116891. | 73116891 | [1] | PIN | MODSHAFT Superseded by part number: A42199 |
| 73116894. | 73116894 | [1] | SCREW | CMI |
| 73116897. | 73116897 | [1] | TRACK ROD END ASSY | CMISUPPORT Superseded by part number: 73129765 |
| 73116898. | 73116898 | [1] | ELECTRIC CABLE | CMICABLE |
| 73116901. | 73116901 | [1] | INSULATOR | CMI |
| 73116905. | 73116905 | [1] | INSULATOR | CMI |
| 73116906. | 73116906 | [4] | GASKET | MODRING |
| 73116908. | 73116908 | [1] | KIT | MOD-CONSISTING OF: |
| 73116944. | 73116944 | [1] | WASHER | CMI |
| 73116949. | 73116949 | [3] | SCREW | MOD |
| 73116953. | 73116953 | [2] | WASHER | CMILOCKWASHER |
| 73116960. | 73116960 | [2] | SEALING WASHER | MODWASHER |
| 73116962. | 73116962 | [13] | SCREW | MOD |
| 73116964. | 73116964 | [2] | SEALING WASHER | MODWASHER |
| 73116966. | 73116966 | [4] | SCREW | MOD |
| 73116970. | 73116970 | [1] | WASHER | MOD Superseded by part number: A40892 |
| 73116976. | 73116976 | [1] | WASHER | MOD Superseded by part number: A41922 |
| 73116977. | 73116977 | [1] | SCREW | MOD |
| 73116982. | 73116982 | [1] | WASHER | CMI |
| 73116986. | 73116986 | [12] | SCREW | MOD |
| 73116988. | 73116988 | [1] | NUT | MOD Superseded by part number: 86017838 |
| 73129765. | 73129765 | [1] | SUPPORT | CMI |
| 73130580. | 73130580 | [1] | SOLENOID | LECSWITCH |
| 73130583. | 73130583 | [1] | BODY | CMICOVER |
| 73130587. | 73130587 | [1] | DRIVEN SPROCKET | CMICOUPLING Superseded by part number: 79086155 |
| 73130590. | 73130590 | [2] | NUT | CMI |
| 73130594. | 73130594 | [1] | ELECTRIC CABLE | CMICABLE Superseded by part number: 71100457 |
| 73130672. | 73130672 | [1] | BOX | CMISUPPORT |
