凯斯零件查询(425) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/85) (A-03) - HITCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
467 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3103053R1
|
[1] |
HITCH ASSY
|
IH
short used w/2 joint PTO shaft
|
| 1. |
3103054R1
|
[1] |
HITCH ASSY
|
IH
long used w/3 joint PTO shaft shaft
|
| 2. |
202956C1
|
[1] |
STRAP
|
IH
hitch
|
| . . |
271562
|
[2] |
SHIELD,Hex, 5/8" - 11 x 2", Gr 5
|
NNA
5/8 x 2 pln type 5 Superseded by part number: 413-1032, 413-1032, NLS
|
| . . |
202708C1
|
[2] |
NUT
|
IH
5/8
|
| 3. |
668037R1
|
[1] |
SUPPORT
|
IH
hitch rop, long hitch
|
| . . |
12258R1
|
[1] |
WASHER
|
IH
.656 x 1.250 x .090 pln Superseded by part number: 25711R1
|
| 4. |
204678C1
|
[1] |
ROPE
|
IH
hitch latch
|
| 5. |
3102360R1
|
[1] |
CHAIN (AG)
|
IH
CHAIN, knotted link
|
| 6. |
202550C1
|
[1] |
FASTENER
|
IH
chain
|
| . . |
179816
|
[1] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
IH
Superseded by part number: 87872
|
| . . |
103320
|
[1] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
674472R1
|
[1] |
BRACKET
|
IH
PIN ASSY, hitch, short hitch
|
| . . |
22106R1
|
[1] |
HEADED PIN,3/4" x 3 3/4"
|
CAS
PIN, 3/4 x 3-3/4 std hd, long hitch Superseded by part number: 439-11260
|
| . . |
517843R1
|
[1] |
COTTER PIN
|
IH
PIN, 3/16 cot Superseded by part number: 86000109
|
