纽荷兰零件查询(FD20) - CRAWLER DOZER (F3.03/1[001]) - ALTERNATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
516 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 14497821. | 14497821 | [4] | WASHER | LEC |
| 24941650. | 24941650 | [1] | BALL BEARING,12mm ID x 32mm OD x 14mm W | TORBEARING |
| 24941660. | 24941660 | [1] | BALL BEARING | LECBEARING Superseded by part number: 87306803 |
| 79022468. | 79022468 | [1] | PLATE | MOD Superseded by part number: 42531218 |
| 79022484. | 79022484 | [1] | KIT | LEC Superseded by part number: 1307188 |
| 79025494. | 79025494 | [1] | RING | TORO-RING |
| 79074702. | 9968592 | [4] | SCREW | LEC |
| 79074704. | 79074704 | [1] | SUPPORT | LEC |
| 79074705. | 79074705 | [1] | ALTERNATOR STATOR | LECSTATOR |
| 79074706. | 79074706 | [2] | SCREW | LEC Superseded by part number: 79093985 |
| 79074707. | 79074707 | [1] | KIT | LEC |
| 79074708. | 79074708 | [1] | SUPPORT | LEC |
| 79074709. | 3079389R1 | [1] | CAPACITOR | IH |
| 79074710. | 79074710 | [3] | LOCK WASHER | LECLOCKWASHER |
| 79074711. | 79074711 | [1] | SCREW | LEC |
| 79074712. | 79074712 | [1] | RECTIFIER | LEC Superseded by part number: |
| 79074713. | 79074713 | [1] | ROTOR | LEC Superseded by part number: 79087247 |
| 79074714. | 75207757 | [1] | GASKET | BHBLINING |
| 79074715. | 79074715 | [1] | VOLTAGE REGULATOR | LEC Superseded by part number: 93158421 |
| 79075883. | 79075883 | [2] | SCREW | MOD Superseded by part number: 93160239 |
