纽荷兰零件查询(FD20) - CRAWLER DOZER (F3.03/2[001]) - ALTERNATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
899 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73119995 | [1] | ALTERNATOR | CMIALTERNATOR (DELCO-REMY 117254) INCLUDES ITEMS 1-67 Superseded by part number: 73160724 |
| . . | 99461190 | [1] | ALTERNATOR | LECAlternator, 24V, 55 Amp Superseded by part number: 98419035 |
| . . | 99461190R | [1] | REMAN-ALTERNATOR | LECREMANUFACTURED 24 VOLT, 55 AMP ALTERNATOR - NA Only Superseded by part number: 87735076R |
| . . | 99461190C | [1] | CORE-ALTERNATOR | LECReturn Number, 24 VOLT, 55 AMP ALTERNATOR - NA Only |
| . . | 87735076R | [1] | REMAN-ALTERNATOR | LECFD20, Reman for new PN 99461190 |
| . . | 87735076C | [1] | CORE-ALTERNATOR | LECReturn Number |
| 1. | 73117047 | [1] | HOUSING | CMIHOUSING, INCLUDES ITEMS 6, 12, 49, 52, 63 |
| 2. | 73117085 | [1] | ROTOR | CMIROTOR |
| 3. | 73117125 | [1] | ALTERNATOR STATOR | CMISTATOR |
| 4. | 73117037 | [1] | FRAME | CMIFRAME, INCLUDES ITEM 64 |
| 5. | 73117127 | [1] | PLATE | CMIPLATE, INCLUDES ITEMS 7, 18 |
| 6. | 73117128 | [1] | DIODE | CMIDIODE(-) |
| 7. | 73117129 | [3] | DIODE | CMIDIODE(+) |
| 8. | 73117092 | [1] | COVER | CMICOVER |
| 9. | 73117093 | [1] | PLATE | CMIPLATE(NOT ILLUSTRATED) |
| 10. | 73117105 | [1] | COIL | CMICOIL |
| 11. | 73119993 | [1] | RECTIFIER | CMIREGULATOR Superseded by part number: 79097751 |
| 11. | 73117043 | [2] | WASHER | CMIWASHER |
| 12. | 73117144 | [1] | BEARING ASSY | CMIBEARING |
| 13. | 73117143 | [1] | RING NUT | CMIRACE |
| 14. | 73117026 | [1] | BEARING ASSY | CMIBEARING |
| 15. | 73117094 | [1] | SCREW | CMISTUD |
| 16. | 73117131 | [1] | TRACK ROD END ASSY | CMITERMINAL |
| 17. | 73119994 | [1] | TERMINAL | CMITERMINAL |
| 18. | 73117132 | [3] | STUD | CMISTUD |
| 19. | 73117114 | [1] | PLATE | CMIPLATE, INCLUDES ITEM 65 |
| 20. | 73117080 | [1] | COLLAR | CMICOLLAR |
| 21. | 73117081 | [1] | COLLAR | CMICOLLAR |
| 22. | 73117107 | [1] | FAN | CMIFAN |
| 23. | 70916964 | [1] | LOCK WASHER | MODLOCKWASHER Superseded by part number: 70904204 |
| 24. | 70917395 | [3] | LOCK WASHER | MKTLOCKWASHER, #8 Superseded by part number: 70906964 |
| 30. | 70917385 | [3] | NUT | CMINUT, #8-32NC Superseded by part number: 70907154 |
| 31. | 70189001 | [1] | NUT | CMINUT Superseded by part number: 73139179 |
| 32. | 73117090 | [4] | SCREW | CMISCREW |
| 33. | 73117087 | [3] | SCREW | CMISCREW |
| 34. | 73117142 | [1] | SCREW | CMISCREW |
| 35. | 73117113 | [1] | SCREW | CMISCREW |
| 37. | 73117072 | [1] | SCREW | CMISCREW W/WASHER ASSY. |
| 39. | 73117032 | [5] | SCREW | CMISCREW W/WASHER ASSY. |
| 40. | 73117033 | [2] | SCREW | CMISCREW W/WASHER ASSY. |
| 41. | 73117031 | [4] | SCREW | CMISCREW W/WASHER ASSY. |
| 45. | 73117021 | [3] | WASHER | CMISEAL |
| 47. | 70189002 | [1] | WASHER | CMIWASHER |
| 48. | 73117089 | [4] | SCREW | CMIBOLT |
| 49. | 73117088 | [1] | BUSHING | CMIBUSHING Superseded by part number: 73133769 |
| 52. | 73117042 | [1] | PLUG | CMIPLUG |
| 53. | 73117079 | [1] | GASKET | CMIGASKET |
| 54. | 73117112 | [1] | GASKET | CMIGASKET |
| 56. | 73117091 | [1] | GROMMET | CMIGROMMET |
| 57. | 73117086 | [1] | INSULATOR | CMIPLATE |
| 58. | 73117062 | [4] | INSULATOR | CMIINSULATOR |
| 63. | 70910231 | [1] | PLUG | BHBPLUG, 1/8""NPT Superseded by part number: 86637724 |
| 64. | 73117061 | [1] | SEAL | CMISEAL |
| 67. | 73117082 | [1] | DEFLECTOR | CMISHIELD |
| 67. | 73117036 | [1] | NUT | CMINUT (NOT ILLUSTRATED) |
| 67. | 73117030 | [1] | SUPPORT | CMISUPPORT (NOT ILLUSTRATED) |
