凯斯零件查询(425) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/85) (A-09) - WHEEL AND AXLE LH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
634 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3102987R1
|
[1] |
STEERING KNUCKLE
|
IH
SPINDLE, wheel LH
|
| . . |
179892
|
[1] |
BOLT,Hex, 1/2" - 13 x 2 3/4", Gr 5
|
IH
1/2 x 2-3/4 pln type 5 Superseded by part number: 87974
|
| . . |
102637
|
[1] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| . . |
103323
|
[1] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
102649
|
[1] |
SLOTTED NUT,5/8"-18, G5
|
IH
NUT, 5/8"-18, G5 Superseded by part number: 87446
|
| . . |
131016
|
[1] |
WASHER
|
IH
.656 x 1.312 x .074 Superseded by part number: 396-21066, 396-21066, NLS
|
| . . |
120169
|
[1] |
COTTER PIN,5/32" x 1"
|
IH
PIN, SPLIT (COTTER), 5/32" x 1" Superseded by part number: 83903970
|
| 2. |
663004R91
|
[1] |
OIL SEAL
|
IH
grease Superseded by part number: B13281
|
| 3. |
651817R1
|
[1] |
BEARING CUP
|
IH
BEARING, wheel inner cup Superseded by part number: 84356153
|
| 3. |
651818R1
|
[1] |
BEARING, wheel inner cone
|
|
| 4. |
203084C91
|
[1] |
HUB
|
IH
ASSY, wheel
|
| 5. |
651814R1
|
[1] |
BEARING CUP
|
IH
BEARING, wheel outer cup Superseded by part number: 36725
|
| 5. |
651815R1
|
[1] |
BEARING, wheel outer cone
|
|
| 6. |
704675R91
|
[1] |
RIM
|
IH
ASSY, wheel, standard, for 6.00 x 16 tire Superseded by part number: K947937
|
| 6. |
3102988R1
|
[1] |
WHEEL
|
IH
RIM ASSY, wheel, wide, for 10/75 x 15 or 11.0L x 15 tire
|
| 7. |
651194R1
|
[1] |
CAP
|
IH
hub
|
| 8. |
351079R1
|
[6] |
BOLT,Hex Counter Shank, 1/2" - 20 x 23/32"
|
IH
wheel Superseded by part number: 32383
|
