| 1. |
UA20551
|
[1] |
RING
|
IH
snap
|
| 2. |
753675R91
|
[1] |
BALL BEARING,35 mm ID x 72 mm OD x 0.984"
|
IH
propellor shaft front
|
| 3. |
754791R1
|
[1] |
BEARING HOUSING
|
IH
BOX, P T O center bearing
|
| . . |
179887
|
[2] |
CABLE
|
NNA
Superseded by part number: 413-828
|
| . . |
103323
|
[2] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
Q3501
|
[2] |
WASHER
|
IH
.781 x 1.250 x .054 pln Superseded by part number: 95-81056
|
| 4. |
753876R3
|
[1] |
BRACKET
|
IH
pivot P T O shaft brg.
|
| . . |
14-1032
|
[1] |
BOLT,Hex, 5/8" - 18 x 2", Gr 5
|
CAS
5/8-NF x 2 pln type 5, Fine Thread Superseded by part number: 88439
|
| . . |
754900R1
|
[1] |
NUT
|
IH
5/8-18 lock
|
| . . |
608081R1
|
[1] |
WASHER
|
IH
.656 x 1.750 x .090 Superseded by part number: 84156177
|
| 5. |
187238
|
[1] |
BOLT,Hex, 1/2" - 13 x 6", Gr 5
|
IH
SCREW, 1/2-13 x 6 hex hd cap Superseded by part number: 86000020
|
| . . |
102637
|
[1] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| . . |
PO10535
|
[2] |
WASHER
|
IH
.531 x 1.250 x .105 pln Superseded by part number: 495-81287
|
| 6. |
3102237R1
|
[1] |
PEDESTAL
|
IH
SUPPORT, PTO shaft bearing pivot bracket complete
|
| 7. |
753874R1
|
[1] |
BUSHING
|
IH
pivot PTO shaft brg upper
|
| 8. |
753875R2
|
[1] |
SHIELD
|
IH
PTO
|
| . . |
179812
|
[2] |
GEAR
|
NNA
5/16 x 1/2 pln type 5 Superseded by part number: 88574
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 9. |
3102240R1
|
[1] |
SPACER
|
IH
|
| 10. |
667623R1
|
[1] |
BUSHING
|
IH
|
| 11. |
20546R1
|
[1] |
SCREW,Hex, 1/2"-13 x 6", G5
|
IH
BOLT, 1/2-13 x 6 type 5 Superseded by part number: 25687R1
|
| . . |
120378
|
[1] |
NUT,Hex, 1/2" - 13, Gr 5
|
IH
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| . . |
120384
|
[1] |
WASHER,1/2"
|
IH
LOCK, 1/2" Superseded by part number: 116121
|
| . . |
20601R1
|
[1] |
WASHER
|
IH
.531 x 1.250 x .105 Superseded by part number: 495-81287
|
