凯斯零件查询(425) - INTERNATIONAL HARVESTER RECTANGULAR BALER (1/76-12/85) (A-13) - PTO SHAFTS WITH CHAINS, FRONT, FITTED WITH LIP SEAL JOURNAL UNITS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
218 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
754793R97
|
[1] |
SHAFT
|
IH
W/CHAIN, PTO, hardy spicer short shafts Superseded by part number: 3103799R91
|
| 1. |
3101183R91
|
[1] |
YOKE
|
IH
quick release assy Superseded by part number: 3103960R91
|
| . . |
3101184R1
|
[1] |
PIN
|
IH
|
| . . |
3101185R1
|
[1] |
VALVE SPRING
|
IH
SPRING
|
| . . |
3101186R1
|
[1] |
PIN
|
IH
tension Superseded by part number: 3101184R1
|
| 2. |
3102316R91
|
[1] |
COUPLING
|
IH
SHAFT AND DOUBLE YOKE W/PIN ASSY, 3101189R1
|
| 3. |
3102317R1
|
[1] |
SHAFT
|
IH
YOKE AND SHAFT ASSY
|
| 4. |
3101189R1
|
[1] |
PIN
|
IH
tension
|
| 5. |
3101012R1
|
[1] |
YOKE
|
IH
end Superseded by part number: 3102313R1
|
| 6. |
3100758R91
|
[1] |
PACKAGE
|
IH
unit, lip seal
|
| . . |
740493R1
|
[1] |
RING
|
IH
retaining
|
| . . |
3100759R1
|
[1] |
GASKET
|
IH
lip seal journal
|
| . . |
3102296R91
|
[1] |
LUBE NIPPLE
|
IH
LUBRICATOR
|
| 7. |
3102308R91
|
[1] |
GUARD
|
IH
ASSY, outer half w/chain, red
|
| . . |
3101268R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN Superseded by part number: 3103278R91
|
| 7. |
3102310R91
|
[1] |
GUARD
|
IH
ASSY, inner half w/chain, red
|
| 8. |
3101190R1
|
[1] |
YOKE
|
IH
end
|
| . . |
754875R1
|
[1] |
NUT
|
IH
end yoke
|
| . . |
3101187R1
|
[1] |
SET SCREW
|
IH
set Superseded by part number: 484-25020
|
