| 1. |
772336R91
|
[6] |
BOLT
|
IH
ASSY, flywheel shear Superseded by part number: 86629539, 83990583, 60451
|
| 2. |
662555R1
|
[2] |
BUSHING,8.46mm ID x 15.98mm OD x 12.83mm L
|
IH
flywheel shear bolt
|
| 3. |
662103R1
|
[1] |
THRUST WASHER
|
IH
flywheel thrust
|
| 4. |
662120R1
|
[1] |
BUSHING
|
IH
flywheel outer
|
| 5. |
3103934R91
|
[1] |
FLYWHEEL
|
IH
W/BUSHING, main drive, replaces 200496C11
|
| 6. |
87414
|
[1] |
LUBE NIPPLE,1/4" - 28
|
NH
FITTING, 1/4-28 str self tap lub
|
| 7. |
202483C91
|
[1] |
HUB
|
IH
PACKAGE, flywheel hub service, consists of ref. no. 2, 8 & 9
|
| 8. |
257611R1
|
[1] |
O-RING,-221, 70 Duro, 1.421" ID x .139" Thk
|
IH
1-7/16 x 1-11/16 x 1/8 flywheel hub Superseded by part number: 70925639
|
| 9. |
667605R1
|
[2] |
SHIM
|
IH
bearing preload .005
|
| 9. |
667606R1
|
[2] |
SHIM
|
IH
bearing preload .007
|
| 9. |
667607R1
|
[2] |
SHIM
|
IH
bearing preload .020
|
| 10. |
3111050R91
|
[1] |
SEAL
|
IH
pinion shaft front oil or Superseded by part number: 380768R91
|
| 10. |
3101165R91
|
[1] |
RETAINER
|
IH
SEAL, pinion shaft front oil Superseded by part number: 3111050R91
|
| 11. |
62923R91
|
[1] |
ROLLER BEARING
|
IH
pinion shaft front cone Superseded by part number: 84385347
|
| 11. |
130503H
|
[1] |
BEARING CUP
|
IH
BEARING, pinion shaft front cup Superseded by part number: 86900365
|
| 12. |
667601R1
|
[1] |
CASE
|
IH
main drive front
|
| . . |
179885
|
[4] |
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5
|
IH
Superseded by part number: 87689
|
| . . |
664573R1
|
[4] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 hex. lock Superseded by part number: 231-4218
|
| . . |
103323
|
[4] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| . . |
178373R1
|
[4] |
WASHER
|
IH
.531 x 1.000 x .056 Superseded by part number: 495-51053
|
| . . |
413-724
|
[10] |
BOLT,Hex, 7/16" - 14 x 1-1/2", Gr 5
|
CAS
7/16 x 1-1/2 pln type 5 Superseded by part number: 9637916
|
| . . |
103322
|
[10] |
LOCK WASHER,7/16"
|
IH
WASHER, LOCK, 7/16" Superseded by part number: 81547
|
| 13. |
107577R1
|
[1] |
BEARING, CUP
|
IH
BEARING, pinion shaft rear cup Superseded by part number: 86613256
|
| 13. |
662062R91
|
[1] |
ROLLER BEARING
|
IH
pinion shaft rear cone
|
| 14. |
204105C1
|
[1] |
SET
|
CAS
GEAR SET, ring and pinion, replaces 662050R11
|
| . . |
272322
|
[1] |
WASHER
|
NNA
7/8-NF pln slt-thick type 5 Superseded by part number: 425-1914
|
| . . |
137218
|
[1] |
COTTER PIN,5/32" x 1 1/4"
|
IH
PIN, SPLIT (COTTER), 5/32" x 1 1/4" Superseded by part number: 86523851
|
| 15. |
662088R1
|
[1] |
SHIM
|
IH
main drive gear .020
|
| 15. |
662089R1
|
[1] |
SHIM
|
IH
main drive gear .007
|
| 15. |
662090R1
|
[1] |
SHIM
|
IH
main drive gear .005, or
|
| 15. |
3102256R1
|
[1] |
SHIM
|
IH
main drive gear .020
|
| 15. |
3102255R1
|
[1] |
SHIM
|
IH
main drive gear .007
|
| 15. |
3102254R1
|
[1] |
SHIM
|
IH
main drive gear .005
|
| 16. |
13390D
|
[1] |
ROLLER BEARING,3.06" ID x 4.3317" OD x 0.866"
|
IH
main drive gear RH cup Superseded by part number: 163044
|
| 16. |
ST2083
|
[1] |
BEARING ASSY
|
IH
BEARING, main drive gear RH cone
|
| 17. |
662091R1
|
[1] |
SHIM
|
IH
main drive bevel gear .005
|
| 17. |
662093R1
|
[1] |
SHIM
|
IH
main drive bevel gear .007
|
| 17. |
662092R1
|
[1] |
SHIM
|
IH
main drive bevel gear .020, or
|
| 17. |
3102257R1
|
[1] |
SHIM
|
IH
main drive bevel gear .005 Superseded by part number: 662091R1
|
| 17. |
3102258R1
|
[1] |
SHIM
|
IH
main drive bevel gear .007 Superseded by part number: 662093R1
|
| 17. |
3102259R1
|
[1] |
SHIM
|
IH
main drive bevel gear .020
|
| 18. |
662017R1
|
[1] |
COVER
|
IH
main drive bevel gear bearing
|
| . . |
181420R1
|
[5] |
SCREW,Hex, 3/8" - 16 x 1", w/ Nylon Pellet
|
IH
3/8-16 x 1 cap Superseded by part number: 310-1616
|
| . . |
103321
|
[5] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 19. |
662066R91
|
[1] |
OIL SEAL,60.33mm ID x 92.15mm OD x 11mm Thk
|
IH
plunger crank RH oil
|
| 20. |
667632R92
|
[1] |
CRANKSHAFT
|
IH
ASSY, plunger
|
| 21. |
668712R92
|
[1] |
BEARING
|
CAS
ASSY, plunger crank RH
|
| 22. |
582816R11
|
[1] |
COLLAR
|
IH
w/setscrew bearing locking Superseded by part number: 47577169
|
| 23. |
668719R91
|
[1] |
BEARING
|
IH
plunger crank Superseded by part number: 668718R92
|
| . . |
673707R1
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
IH
BOLT, 1/2 x 1-1/2 pln crg type 5
|
| . . |
102637
|
[4] |
NUT,1/2"-13, G5
|
IH
Superseded by part number: 280431
|
| 25. |
152127H1
|
[1] |
BREATHER,1/8"-27, Short
|
IH
VENT ASSY, main drive gear box, or Superseded by part number: 219-433
|
| 25. |
895120H1
|
[1] |
NO LONGER SERVICED
|
IH
VENT ASSY, main drive gear box Superseded by part number: 152127H1
|
| 26. |
444676
|
[1] |
DRAIN PLUG,Sq Soc, 1"-11 1/2, NTPF
|
IH
PLUG, 1-11-1/2 auto sq soc hd pipe Superseded by part number: 221-846
|
| 28. |
667603R1
|
[1] |
GASKET
|
IH
main drive gear box cover
|
| 29. |
672199R1
|
[1] |
COVER
|
IH
ASSY, main drive gear case rear
|
| . . |
179816
|
[13] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
IH
Superseded by part number: 87872
|
| . . |
103320
|
[13] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 30. |
670568R1
|
[1] |
HUB
|
IH
main bevel gear
|
| . . |
181432
|
[10] |
BOLT,Hex, 1/2" - 20 x 1 5/8", Gr 5
|
IH
1/2NF x 1-5/8 pln type 5 Superseded by part number: 181701
|
| 31. |
261622R1
|
[1] |
PLATE, LOCKING
|
IH
LOCK PLATE, main drive gear hub cap screw
|
| 32. |
444574
|
[1] |
PLUG,Sq Hd, 1/4"-18 NPTF
|
IH
1/4-28 automotive sq hd pipe
|
| 33. |
667604R1
|
[1] |
CAP
|
IH
main drive bevel gear
|
| 34. |
201580C1
|
[1] |
PLATE
|
IH
bolt holder
|
| . . |
181364
|
[2] |
BOLT,Hex, 3/8" - 24 x 1", Gr 5
|
IH
3/8-NF x 1 pln type 5 Superseded by part number: 88374
|
| 36. |
200525C1
|
[1] |
WASHER
|
IH
plunger crankshaft thrust
|
| 37. |
22396V
|
[1] |
BEARING, CUP,112.739mm OD x 30.37mm W
|
IH
BEARING, main drive gear cup Superseded by part number: 510892
|
| 37. |
9718528R91
|
[1] |
BEARING, main drive gear cone
|
|
| 38. |
217-519
|
[1] |
DRAIN PLUG,Sq Hd, 1/2"-14 NPTF
|
CAS
PLUG, , Automotive, Pipe Sq Hd, 1/2"-14 NPTF
|
| 39. |
667600R2
|
[1] |
CASE
|
IH
main drive rear
|
| . . |
271558
|
[2] |
HOOD,Hex, 5/8" - 11 x 1 1/2", Gr 5
|
NNA
5/8 x 1-1/2 pln type 5 Superseded by part number: 413-1024, 413-1024, NLS
|
| . . |
103325
|
[2] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| . . |
322593R1
|
[2] |
BOLT
|
IH
w/nylon pellet, 3/4 x 2-1/4
|
| . . |
103326
|
[2] |
LOCK WASHER,3/4"
|
IH
WASHER, LOCK, 3/4" Superseded by part number: 87340
|
