日立零件查询（CS125）CANOPY Hitachi HOP online
广数供应链运营团队, 15 02月, 2025，浏览：
296 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 00. | 425304 | [1] | ROOF | |
| 02. | 425360 | [1] | SUPPORT | |
| 03. | 425361 | [1] | SUPPORT | |
| 04. | 425182 | [4] | RUBBER;CUSHION | |
| 05. | 425183 | [4] | PACKING | |
| 06. | 425184 | [4] | WASHER | |
| 07. | 500122 | [2] | BOLT | |
| 08. | 947325 | [4] | WASHER;PLANE | |
| 09. | 947864 | [8] | NUT | |
| 10. | 500197 | [2] | BOLT | |
| 11. | 425323 | [1] | POLE | |
| 12. | 425324 | [1] | POLE | |
| 13. | 425186 | [2] | SHAFT | |
| 15. | 947858 | [8] | NUT | |
| 16. | 947327 | [4] | WASHER;PLANE | |
| 17. | 425256 | [1] | RUBBER | |
| 18. | 425236 | [1] | CYL. | |
| 19. | 424919 | [2] | PIN;LOCK | |
| 20. | 947323 | [2] | WASHER;PLANE | |
| 21. | 425275 | [8] | BUSHING | |
| 22. | 425399 | [1] | PIN | |
| 23. | 925263 | [1] | PIN;SPRING | |
| 24. | 425274 | [1] | PLATE | |
| 25. | 425173 | [1] | RUBBER;CUSHION | |
| 28. | 439860 | [4] | SCREW;SEMS | |
| 29. | 425188 | [2] | BUSHING | |
