| 1. |
674059R2
|
[1] |
LARGE PLATE
|
IH
PLATE, bottom extension
|
| 2. |
3101518R2
|
[1] |
ANGLE
|
IH
plunger guide thrust
|
| . . |
754828R1
|
[8] |
BOLT,#3, 3/8" - 24 x 1 3/8"
|
IH
3/8-24 x 1-3/8 znd no. 3 plow
|
| . . |
21741R1
|
[8] |
WASHER
|
IH
.406 x .875 x .105 Superseded by part number: 495-81133
|
| . . |
103321
|
[8] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| . . |
103026
|
[8] |
NUT,3/8"-24, G5
|
IH
Superseded by part number: 129-123
|
| 3. |
203015C1
|
[1] |
PLATE
|
IH
STRIP, plunger thrust Superseded by part number: 203015C2, 664542R1
|
| . . |
179816
|
[4] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
IH
Superseded by part number: 87872
|
| . . |
179817
|
[2] |
BOLT,Hex, 5/16" - 18 x 7/8", Gr 5, Full Thd
|
IH
Superseded by part number: 280345
|
| . . |
179818
|
[2] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5
|
IH
Superseded by part number: 9635884
|
| . . |
179820
|
[1] |
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 5
|
IH
Superseded by part number: 87657
|
| . . |
103320
|
[9] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| . . |
22859R1
|
[9] |
WASHER
|
IH
.344 x .750 x .164 Superseded by part number: 495-81113
|
| 4. |
665450R1
|
[4] |
SEAL
|
IH
SEAL, pitman brg front oil Superseded by part number: 665728R1
|
| 5. |
664975R1
|
[2] |
BEARING LINER
|
IH
INSERT, pitman bearing front
|
| 6. |
109461
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
IH
NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg Superseded by part number: 80710
|
| 7. |
665716R1
|
[1] |
BEARING ASSY, pitman front
|
|
| . . |
179874
|
[2] |
BOLT,Hex, 7/16" - 14 x 4", Gr 5
|
IH
Superseded by part number: 280130
|
| . . |
3063614R1
|
[2] |
NUT
|
IH
7/16-14 hex. lock
|
| 8. |
3102233R91
|
[1] |
PITMAN
|
IH
W/BUSHING
|
| . . |
80717
|
[1] |
LUBE NIPPLE,45 Degree, 1/8" NPT x 7/8" lg
|
NH
FITTING, 1/8-27 45 deg angle lub
|
| 9. |
668359R1
|
[1] |
BLOCK
|
IH
pitman
|
| 10. |
664976R1
|
[2] |
BUSHING,31.8mm ID x 34.95mm OD x 44.7mm L
|
IH
pitman rear
|
| 11. |
668358R91
|
[1] |
SUPPORT
|
IH
BLOCK ASSY, plunger pitman
|
| . . |
673707R1
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
IH
BOLT, 1/2 x 1-1/2 pln crg type 5
|
| . . |
664573R1
|
[4] |
LOCK NUT,1/2"-13, GB
|
IH
NUT, 1/2-13 hex lock Superseded by part number: 231-4218
|
| . . |
103323
|
[4] |
LOCK WASHER,1/2"
|
IH
WASHER, LOCK, 1/2" Superseded by part number: 87326976
|
| 12. |
12258R1
|
[2] |
WASHER
|
IH
21/32 x 1-1/4 x 0.090 Superseded by part number: 25711R1
|
| 13. |
672925R91
|
[1] |
ROLLER, plunger, or
|
|
| 13. |
202164C92
|
[1] |
BEARING ASSY,16.08 mm ID x 50.8 mm OD x 15 mm
|
IH
roller plunger Superseded by part number: 47577176
|
| 14. |
3100954R1
|
[1] |
SPRING
|
IH
plunger front scraper
|
| . . |
100776
|
[2] |
|
NNA
no. 2 x 3/8 pln r/hds mach Superseded by part number: NLS
|
| . . |
106498
|
[2] |
LOCK WASHER,#12
|
IH
Washer, Lock, #12 Superseded by part number: 492-11012
|
| . . |
557109R1
|
[2] |
WASHER
|
IH
.266 x .500 x .054 pln
|
| 15. |
668367R1
|
[1] |
PAD
|
IH
wear
|
| . . |
179814
|
[2] |
SPACER
|
NNA
Superseded by part number: 13-510, 13-510, 80179814
|
| 16. |
668981R1
|
[2] |
SHIM
|
IH
plunger lower, (or as required)
|
| 17. |
868368R1
|
[4] |
|
P
SHIM, plunger lower, (or as required)
|
| 18. |
668365R1
|
[2] |
SHIM,45.72mm OD x 0.76mm Thk
|
IH
plunger upper, (or as required)
|
| 19. |
668364R2
|
[1] |
BLOCK
|
IH
plunger upper right
|
| . . |
453838
|
[2] |
NUT
|
IH
5/16 znp 3 long prg base tee
|
| 20. |
203021C1
|
[1] |
KNIFE
|
IH
hay
|
| . . |
15588R1
|
[3] |
PLOW BOLT,#3, 5/8" - 11 x 1 1/2", Gr 2
|
IH
BOLT, PLOW, 5/8"-11 x 1 1/2", G2, Full Thd
|
| . . |
102639
|
[3] |
NUT,5/8"-11, G5
|
IH
Superseded by part number: 280374
|
| . . |
103325
|
[3] |
LOCK WASHER,5/8"
|
IH
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| . . |
3103078
|
[1] |
SHIM, knife
|
|
| 23. |
3101504R1
|
[1] |
BLOCK
|
IH
plunger upper center
|
| . . |
598811R1
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5
|
IH
BOLT, 3/8 x 1-3/4 crg type 5 Superseded by part number: 86508775
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| 24. |
3101375R1
|
[2] |
SPACER
|
IH
plunger center block, (or as required)
|
| 25. |
204752C1
|
[2] |
BAR
|
IH
plunger center block
|
| 26. |
3100953R1
|
[1] |
SPRING
|
IH
scraper rear
|
| 27. |
202241C1
|
[1] |
BLADE
|
IH
SUPPORT, plunger rear scraper
|
| . . |
181313
|
[1] |
BOLT,Hex, 1/4" - 28 x 3/4", Gr 5
|
IH
1/4-NF x 3/4 pln type 5 Superseded by part number: 26620R1
|
| . . |
106260
|
[1] |
WASHER,#12
|
IH
.250 x .562 x .036 pln Superseded by part number: 495-81252
|
| . . |
103319
|
[1] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| . . |
21756R1
|
[1] |
WASHER
|
IH
.469 x .750 x .027 Superseded by part number: 86624145
|
| 28. |
3100350R1
|
[1] |
SPACER
|
IH
plunger rear
|
| 29. |
667925R91
|
[2] |
ROLLER BEARING,0.628" ID x 2" OD x 15 mm
|
IH
ROLLER, plunger, or Superseded by part number: 47577176
|
| 29. |
3103919R91
|
[2] |
|
IH
BEARING, plunger roller Superseded by part number: 202164C92
|
| . . |
413-1024
|
[1] |
BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5
|
CAS
5/8 x 1-1/2 pln type 5 Superseded by part number: 88062
|
| . . |
21793R1
|
[1] |
WASHER
|
IH
.656 x 1.250 x .164 Superseded by part number: 495-81179
|
| 30. |
3103021R1
|
[1] |
PLUNGER
|
IH
ASSY
|
| 31. |
3103279R1
|
[1] |
PIVOT
|
IH
BUSHING, plunger slide
|
| 32. |
3103024R1
|
[1] |
ANGLE
|
IH
plunger slide
|
| . . |
492-11025
|
[2] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| . . |
179795
|
[2] |
TILLAGE BLADE
|
NNA
1/4 x 3/4 pln type 5 Superseded by part number: 413-412
|
| 33. |
3103023R1
|
[1] |
SLIDE
|
IH
plunger
|
| . . |
413-1044
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-3/4", Gr 5
|
CAS
5/8 x 2-3/4 pln type 5 Superseded by part number: 88693
|
| . . |
496-21066
|
[1] |
WASHER,16.6mm ID x 33.5mm OD x 3.8mm Thk
|
CAS
.656 x 1.312 x .074 pln Superseded by part number: 5122064
|
| . . |
3100765R1
|
[1] |
NUT
|
IH
5/8 lock Superseded by part number: 3100765R2
|
| 34. |
674057R1
|
[1] |
ANGLE
|
IH
plunger guide
|
| . . |
179835
|
[6] |
BOLT,Hex, 3/8" - 16 x 5/8", Gr 5, Full Thd
|
IH
Superseded by part number: 88703
|
| . . |
477242R1
|
[6] |
WASHER
|
IH
.406 x 1.000 x .027
|
| 35. |
667922R1
|
[1] |
BOLT,Eye, 5/8" - 11 x 4.69"
|
IH
plunger eye
|
| . . |
1145085
|
[2] |
NUT, 1/2 pln jam type 5
|
|
| 36. |
202244C1
|
[1] |
ANGLE
|
IH
plunger runner
|
| . . |
NLS
|
[3] |
NO LONGER SERVICED
|
BAS
5/8 x 1-1/2 type 5
|
| . . |
280374
|
[3] |
NUT,Hex, 5/8" - 11, Gr 5
|
NH
5/8 type 5
|
| . . |
492-11062
|
[3] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 37. |
608701R1
|
[1] |
WASHER
|
IH
21/32 x 1-1/4 x .054 znd Superseded by part number: 86624155
|
| 38. |
202247C1
|
[1] |
WASHER
|
IH
front scraper
|
| 39. |
202240C1
|
[1] |
STRIPPER
|
IH
SUPPORT, plunger front scraper
|
| . . |
271562
|
[1] |
SHIELD,Hex, 5/8" - 11 x 2", Gr 5
|
NNA
5/8 x 2 pln type 5 Superseded by part number: 413-1032, 413-1032, NLS
|
