| 1. |
667761R1
|
[3] |
SHIM
|
IH
packer gear wear, (or as required)
|
| 2. |
667760R1
|
[1] |
STRIP
|
IH
packer gear wear
|
| . . |
17351R1
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
|
IH
BOLT, 3/8 x 1 crg type 1 Superseded by part number: 88682
|
| . . |
102635
|
[2] |
NUT,3/8"-16, G5
|
IH
Superseded by part number: 280136
|
| . . |
103321
|
[2] |
LOCK WASHER,3/8"
|
IH
WASHER, LOCK, 3/8" Superseded by part number: 80680
|
| 3. |
667759R4
|
[1] |
GEAR
|
IH
packer drive lower Superseded by part number: 667759R5
|
| 4. |
669016R1
|
[1] |
KEY
|
IH
3/8 x 2-3/4 taper gib
|
| 5. |
671631R1
|
[1] |
RETAINER
|
IH
packer gear key
|
| . . |
426816
|
[1] |
SCREW,Hex Soc Hd, 1/4"-20 x 3/4"
|
IH
1/4 x 3/4 h/shd cap Superseded by part number: 61-32512
|
| . . |
103319
|
[1] |
LOCK WASHER,1/4"
|
IH
WASHER, LOCK, 1/4" Superseded by part number: 92-11025
|
| . . |
21795R1
|
[2] |
WASHER,1.78" ID x 2.5" OD x 0.03" Thk
|
IH
1.781 x 2.250 x .027, (or as required) Superseded by part number: 495-81005
|
| . . |
20705R1
|
[1] |
WASHER
|
IH
1.781 x 2.500 x .054, (or as required) Superseded by part number: 87613203
|
| 6. |
3102815R2
|
[1] |
SHIELD
|
IH
COVER ASSY, packer drive
|
| . . |
18764R1
|
[2] |
HARDWARE,Hex, 5/16"-18 x 3/4", G2
|
IH
BOLT, 5/16 x 3/4 type 1 Superseded by part number: 424-512
|
| . . |
16897R1
|
[4] |
CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd
|
IH
BOLT, 5/16 x 3/4 crg type 1 Superseded by part number: 412-512
|
| . . |
120376
|
[4] |
NUT,5/16"-18, G5
|
IH
Superseded by part number: 9635082
|
| . . |
670472R1
|
[2] |
SPRING NUT,J, Ret, 5/16"-18
|
IH
5/16-18 spring Superseded by part number: 131-890
|
| . . |
80681
|
[4] |
LOCK NUT,5/16"
|
NH
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| . . |
138538
|
[2] |
LOCK WASHER
|
IH
WASHER, 5/16 int-tooth lock Superseded by part number: 23060R1
|
| 7. |
3101680R1
|
[1] |
SUPPORT
|
IH
packer drive cover
|
| . . |
9635082
|
[2] |
NUT,5/16" - 18, Gr 5
|
NH
5/16 pln hex
|
| . . |
103320
|
[2] |
LOCK WASHER,5/16"
|
IH
WASHER, LOCK, 5/16" Superseded by part number: 322358, 83990583
|
| 8. |
3101679R1
|
[1] |
SHEET
|
IH
feed opening front
|
| . . |
24407R1
|
[3] |
SELF-TAP SCREW,Cross Pan Hd, 1/4" x 1/2"
|
IH
SCREW, SELF TAPPING, Cross Pan Hd, 1/4" x 1/2" Superseded by part number: 905988R1
|
| . . |
120393
|
[2] |
BEARING WASHER,5/16", SAE
|
IH
WASHER, .344 x .688 x .051 Superseded by part number: 28588R1
|
| 9. |
Q1497
|
[1] |
KEY,Gib, 3/8" Sq x 2"
|
IH
3/8 x 2 taper gib hd tappered
|
| 10. |
668766R1
|
[1] |
RETAINER
|
IH
packer drive shaft lower key
|
| . . |
179816
|
[1] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
IH
Superseded by part number: 87872
|
| 11. |
667769R1
|
[1] |
GEAR
|
IH
drive lower pinion
|
| . . |
21794R1
|
[1] |
WASHER
|
IH
1.406 x 2.000 x .033 Superseded by part number: 495-81212
|
| 12. |
608085R1
|
[4] |
WASHER
|
IH
1-13/32 x 2 x 16 ga znd, (or as required) Superseded by part number: 495-81213
|
| 13. |
668325R1
|
[1] |
SPACER
|
IH
lower packer pinion
|
| 14. |
668369R91
|
[1] |
FLANGED BEARING
|
IH
ASSY, packer drive lower Superseded by part number: 546661R91
|
| . . |
550796R1
|
[2] |
CARRIAGE BOLT,3/8" - 16 x 1 1/4", Grade 5
|
IH
BOLT, 3/8 x 1-1/4 crg type 5 Superseded by part number: 86508749
|
| 15. |
656955R1
|
[1] |
STUD
|
IH
lower packer bearing dowel
|
| . . |
138549
|
[1] |
LOCK WASHER,Int Tooth, 1/2"
|
IH
WASHER, LOCK, Int Tooth, 1/2" Superseded by part number: 20355
|
| 16. |
667762R1
|
[1] |
SHAFT
|
IH
packer drive
|
| 17. |
667863R91
|
[1] |
BEARING ASSY,4.9375" OD x 0.875"
|
IH
ASSY, packer drive upper
|
| . . |
598811R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5
|
IH
BOLT, 3/8 x 1-3/4 crg type 5 Superseded by part number: 86508775
|
| . . |
598812R1
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2", Gr 5
|
IH
BOLT, 3/8 x 2 crg type 5 Superseded by part number: 280661
|
| 18. |
452563
|
[1] |
KEY
|
IH
5/16 x 2-1/8 Woodruff Superseded by part number: 57388D
|
| 20. |
667766R1
|
[1] |
GEAR
|
IH
packer drive upper pinion
|
| . . |
220724
|
[1] |
BOLT,Hex Hd, Lock, 7/16"-14 x 1 1/4", G5
|
IH
BOLT, 7/16 x 1-1/4 lock type 5 Superseded by part number: 70427R1
|
| 21. |
667698R1
|
[1] |
WASHER
|
IH
packer drive shaft upper
|
