纽荷兰零件查询(FD20) - CRAWLER DOZER (C1.01[001]) - BRAKE FOOT CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
692 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 595208. | 595208 | [1] | WASHER | MOD |
| 4968985. | 4968985 | [2] | PLATE | LEC |
| 4973457. | 4973457 | [2] | SPRING | LEC Superseded by part number: 76011888 |
| 4974992. | 4974992 | [2] | YOKE | LECFORK |
| 10005010. | 10005010 | [4] | PIN | MKT Superseded by part number: 10005011 |
| 10005110. | 10005110 | [2] | PIN | LEC |
| 10249510. | 10249510 | [2] | PIN | LEC |
| 10517170. | 10517170 | [6] | WASHER,14.2mm ID x 24.1mm OD x 3.5mm Thk | MKTLOCKWASHER Superseded by part number: 10572074 |
| 10520001. | 10520001 | [2] | WASHER,12.2mm ID x 22mm OD x 3mm Thk | BHB Superseded by part number: 17095304 |
| 10520101. | 10520101 | [6] | WASHER,14.4mm ID x 26mm OD x 3mm Thk | TTF Superseded by part number: 17095504 |
| 10733601. | 10733601 | [4] | COTTER PIN,M3.2 x 22 | TTFPIN, SPLIT (COTTER), M3.2 x 22 |
| 10791311. | 10791311 | [4] | THIN NUT,M14 x 1.5, Cl 04 | TTFNUT Superseded by part number: 16980331 |
| 11066275. | 11066275 | [4] | LOCKING RING | MKTLOCKRING Superseded by part number: 11066276 |
| 11115531. | 11115531 | [6] | BOLT,Hex, M14 x 30, 10.9, Full Thd | LEC Superseded by part number: 11115534 |
| 11118737. | 11118737 | [8] | SCREW | LEC Superseded by part number: 11118731 |
| 14557870. | 14557870 | [2] | BUSHING | LECBUSH |
| 79004228. | 79004228 | [2] | SHAFT | LECLEVEL AND PIN ASSY. |
| 79005240. | 79005240 | [8] | WASHER,16.8mm ID x 36mm OD x 8mm Thk | LEC |
| 79006975. | 79006975 | [3] | BUSHING,28mm ID x 33.03mm OD x 50mm L | LECBUSH |
| 79007104. | 79007104 | [2] | LEVER | LEC Superseded by part number: 76035545 |
| 79007715. | 79007715 | [2] | STRUT | LEC |
| 79007718. | 79007718 | [2] | SHAFT | LEC |
| 79007729. | 79007729 | [1] | CROSSRAIL | LEC |
| 79007730. | 79007730 | [2] | SPACER | LEC |
| 79009676. | 79009676 | [1] | ARM | LECPEDAL |
| 79009677. | 79009677 | [1] | ARM | LECPEDAL |
| 79011553. | 79011553 | [4] | SCREW | LEC |
| 79015261. | 79015261 | [1] | SPRING | LEC |
| 79015262. | 79015262 | [1] | SPRING | LEC |
| 79016054. | 79016054 | [1] | SUPPORT | LEC |
| 79016159. | 79016159 | [2] | LEVER | LEC |
| 79016220. | 79016220 | [4] | TIE-ROD | LECROD |
| 79016224. | 79016224 | [2] | PIN | LEC |
| 79016543. | 79016243 | [1] | SUPPORT | LEC |
